100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction
100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction
100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction
100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction
Specifications
Brand Name :
T-WORKS
Model Number :
ZYC100B-B1
Certification :
ISO9001/SGS / GOST/CE
Place of Origin :
Hunan, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
15 sets per month
Delivery Time :
30 days after deposit received
Packaging Details :
Nude packing for main body, plastic package for main parts
Product name :
Hydraulic Jack In Piling Machine
Efficiency :
98%
Suitable pile :
Concrete spun pile, square pile, steel tube, H-pile
Piling Speend(m/min) :
6.5
Suitable pile size :
Max 350mm for round, 350m for squre
Description

High Efficiency 100T Mini Jack In Piling Machine For Pile Pressing Machine

1. Description:

Hydraulic Static Pile Drivers are featured with no noise, no vibration, no pollution and no rubbish left in construction site.It can work with H-piles, precast concrete and steel piles with different shapes,like round,square and tapered shape. There are series models range from 60T to 1200T

It is adopted the hydraulic system design of large power and high flow,the precast pile entirely depends on the hydraulic static pressure so that the pile can be pressed into the ground steadily and quietly.

The pressing-pile speed amounting to 300-800 meters within 8hours, which its quite more efficient than other conventional pile drivers.

This unique construction method with non-pollution has gradually taken place of the pile hammer.

100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction

2. Applications:

  • Clay, soft soil, sand layer, etc.
  • Noise regulated area
  • Vibration regulated area

​100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction

3. Specifications:

Parameter/Model ZYC100
Rate piling pressure(KN) 1000
Piling speed(m/min) Fast 6.5
Low 3.0
Piling stroke(m) 1.6
Pace(m) Longitudinal 1.5
Horizontal 0.4
Angle range(°) 15
Rise stroke(m) 1.45
Square pile(mm) Max 350
Circle pile(mm) Max 350
Side piling space(mm) 400
Corner piling space(mm) 800
Lifting weight(t) 5
Pile hanging length(m) 9
Power(KW) Piling 37
Lifting 11
Main dimension(m) Work length 6.7
Work width 4.2
Transportation height 2.7
Total weight(t) 100

4. Feature Advantage:

1). Civilized construction; Clean; No noise; No vibrations; No construction wastes.
2). Reliable Construction Quality; Piling process is similar to static load testing, where pile bearing force can be displayed. 100% pile success rate is guaranteed.
3). Fast piling and High efficiency; One Hydraulic Static Pile Driver (shortened as HSPD )can drive piles in total of 600~800m per 8 hours, much faster than other modes. Especially suitable for large-scale or time-constraint projects.
4). Walking and steering freely. Easy to align piles.
5). Compact conformation. Easy to disassemble & assemble.

100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction

100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction

100T Mini Hydraulic Jack In Piling Machine 50KN Lifting Weight Unique Design For Construction

​​
