100KN Single Acting Jack NPT3/8 Oil Inlet Hydraulic Cylinder Bearing 100KN
100KN Single Acting Jack NPT3/8 Oil Inlet Hydraulic Cylinder Bearing 100KN
100KN Single Acting Jack NPT3/8 Oil Inlet Hydraulic Cylinder Bearing 100KN
100KN Single Acting Jack NPT3/8 Oil Inlet Hydraulic Cylinder Bearing 100KN
Specifications
Brand Name :
AI LE SEN
Model Number :
RC
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiate
Payment Terms :
D/P, T/T
Supply Ability :
200 Set Every month
Delivery Time :
4-5 weeks
Packaging Details :
Wooden boxes that can be transported by air or cardboard boxes
product name :
Hydraulic Cylinders
load capacity :
100KN
Work Pressure :
0-700Bar
Oil Inlet :
NPT3/8
Outside diameter :
57
Material :
Alloyed steel
Description

RC-Series Single-Acting Hydraulic Cylinder Bearing Capacity 100KN

Product description

1. Outer ring threads, plunger threads and bottom mounting holes allow for easy positioning

2. Excellent design works in any mounting position

3. Removable handle for easier fixing (select models only)

4. High Strength Return Spring

5. The surface can choose to paint or black

6. Nickel-plated finish available on most models

Technical data

Type

Carrying capacity

(KN)

stroke

mm

Outside diameter

mm

height

mm

weight

kg
RC-101

100

 26 57 89 1.9
RC-102 54 57 121 2.4
RC-104 105 57 171 3.4
RC-106 156 57 247 4.5
RC-108 203 57 298 5.6
RC-1010 257 57 349 6.8
RC-1012 304 57 400 7
RC-1014 356 57 450 8.5

Notice

1. All cylinders can be supplied as a complete set including pump, tubing, fittings

2. The data in the above table is subject to deviation and is for reference only. Subject to actual data.
