Specifications
Brand Name :
Kobelco
Model Number :
PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable price
Payment Terms :
Western Union, T/T
Supply Ability :
300pcs /Month
Delivery Time :
5-8 Weekdays
Packaging Details :
Wooden case or as required
Product name :
PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original
Applicable machine model： :
Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator
Applicable Industries： :
Mechanical repair shops, retail, construction, energy, mining
category :
Hydraulic Pump
Condition :
NEW/REBUILT
Brand :
Kobelco
Description

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

PRODUCT DESCRIPTION
Model: PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original category: Hydraulic Pump
Brand: Kobelco Place of Origin:Other Country
Condition: Original & Oem Warranty: 12 months
MOQ: 1 pcs Production Capacity: 1000pcs /Month
Standard or Nonstandard: Standard Payment Term: L/C,T/T, Western Union, Tradeassurance
Delivery Time: 1-3 days (depend on order) Means of Transport: By Sea, Air or DHL/FEDEX/TNT/EMS
Guarantee: We will check and send detailed pictures to buyers for confirmation

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

Pos. Part No Qty Parts name Comments
PY10V00003F1 [1] PUMP
Consists Of Ref. Numbers : 11-954
11 PY10V00003S011 [1] PISTON ASSY.
13 PY10V00003S013 [1] CYLINDER
30 PY10V00003S030 [1] TRAY
41 PY10V00003S041 [2] VALVE POPPET
111 PY10V00003S111 [1] CLIP, SPRING
114 PY10V00003S114 [1] TRANSMISSION SLEEVE
123 PY10V00003S123 [1] ROLLER BEARING
124 PY10V00003S124 [1] BEARING
127 2441U398S127 [1] SPACER
130 PY10V00003S130 [1] TURBINE
141 NSS [1] NOT SOLD SEPARAT Cylinder
151 NSS [10] NOT SOLD SEPARAT Piston
152 NSS [10] NOT SOLD SEPARAT Ring, Thrust
153 PY10V00003S153 [1] PLATE
156 2437U188S156 [1] BUSHING
157 2437U188S157 [10] SPRING
158 2437U188S158 [1] THRUST RING
211 PY10V00003S211 [1] LARGE PLATE PLATE, LARGE
212 NSS [1] NOT SOLD SEPARAT Plate, Face
214 NSS [1] NOT SOLD SEPARAT Bushing
251 PY10V00003S251 [1] COUPLING FLANGE
261 PY10V00003S261 [1] COVER
271 PY10V00003S271 [1] HOUSING
273 PY10V00003S273 [1] COVER
313 NSS [1] NOT SOLD SEPARAT Plate, Distribution
352 PY10V00003S352 [1] COVER
363 PY10V00003S363 [1] TRANSMISSION SLEEVE
365 NSS [1] NOT SOLD SEPARAT Seat
366 NSS [1] NOT SOLD SEPARAT Stop
367 NSS [1] NOT SOLD SEPARAT Ball
401 ZS23C10045 [8] SCREW,Hex Socket Head, M10 x 45mm
402 ZS23C08040 [2] SCREW,Hex Socket Head, M8 x 40mm
406 ZS23C06016 [10] SCREW,Hex Socket Head, M6 x 16mm
408 ZS23C06025 [2] SCREW,Hex Socket Head, M6 x 25mm
416 ZS23C08030 [4] SCREW,Hex Socket Head, M8 x 30mm M8 x 30
424 ZS23C12030 [4] SCREW,Hex Socket Head, M12 x 30mm
466 2441U667S466 [2] PLUG
467 2441U436S468 [1] PLUG
468 2441U549S464 [1] PLUG
490 2441U722S490 [9] PLUG
492 2436U1165S152 [2] PLUG
508 PY10V00003S508 [2] RESTRICTOR
530 PY10V00003S530 [1] BALL JOINT
531 NSS [1] NOT SOLD SEPARAT Ball Joint
532 PY10V00003S532 [1] PISTON
534 PY10V00003S534 [1] TAPPET
548 NSS [1] NOT SOLD SEPARAT Pin
551 PY10V00003S551 [1] COVER
611 PY10V00003S611 [1] LEVER
621 PY10V00003S621 [1] PISTON
622 PY10V00003S622 [1] CYLINDER
624 PY10V00003S624 [1] SPRING SEAT
625 PY10V00003S625 [1] SPRING
626 PY10V00003S626 [1] SPRING
627 2450U45S627 [1] STEP
628 2436U2455S628 [1] ADJUSTMENT SCREW
630 2436U1378S630 [1] NUT
641 PY10V00003S641 [1] BLOCK ASSY.
PY10V00003R100 [1] REPAIR KIT
Consists Of Ref. Numbers : 651, 652
651 PY10V00003S651 [1] SLEEVE
652 PY10V00003S652 [1] SPOOL
653 2441U722S617 [2] PIN
654 2441U723S885 [1] PIN
700 ZD12G03500 [1] O-RING,34.40mm ID x 40.60mm OD x 3.10mm
701 ZD12G07000 [1] O-RING,69.40mm ID x 75.60mm OD x 3.10mm
702 ZD12G14500 [1] O-RING,144.40mm ID x 150.60mm OD x 3.10mm
704 ZD12G02500 [1] O-RING,24.40mm ID x 30.60mm OD x 3.10mm
705 ZD12P01600 [1] O-RING
706 ZD12P01100 [4] O-RING
707 ZD12P01800 [1] O-RING
708 ZD12P00700 [3] O-RING,1.6mm Thk x 6.8mm ID, 90 Duro
709 ZD12P02600 [1] O-RING
710 ZD12P02000 [1] O-RING,2.4mm Thk x 19.8mm ID, 90 Duro
711 ZD12P01400 [1] O-RING
751 PY10V00003S751 [1] GASKET
752 PY10V00003S752 [1] GASKET
774 2441U398S778 [1] OIL SEAL
792 ZD85G02500 [1] BACK-UP RING
801 ZN11C08005 [1] NUT
802 ZN11C16013 [1] NUT
824 2441U398S820 [1] RING
825 ZR26X01300 [1] RING, SNAP RING SNAP
885 ZP26D06012 [1] PIN
901 PY10V00003S901 [1] BOLT
924 2441U691S923 [1] SCREW
954 2437U185S510 [1] SET SCREW

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original

PY10V00003F1 For Kobelco SK45-2 SK045 50UR-2 SK35-8 45-8 Excavator Parts Hydraulic Piston Pump K3SP30-110R-9001 MAIN PUMP PUMP DEVICE Hydraulic Pump PUMP DEVICE Aftermarket Original
