Specifications
Brand Name :
CAT
Model Number :
162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable price
Payment Terms :
Western Union, T/T
Supply Ability :
300pcs /Month
Delivery Time :
5-8 Weekdays
Packaging Details :
Wooden case or as required
Product name :
162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original
Applicable machine model： :
Cat D6R II TRACK-TYPE TRACTOR
Applicable Industries： :
Mechanical repair shops, retail, construction, energy, mining
category :
Hydraulic Pump
Condition :
NEW/REBUILT
Brand :
CAT
Description

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

PRODUCT DESCRIPTION
Model: 162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original category: Hydraulic Pump
Brand: CAT Place of Origin:Other Country
Condition: Original & Oem Warranty: 12 months
MOQ: 1 pcs Production Capacity: 1000pcs /Month
Standard or Nonstandard: Standard Payment Term: L/C,T/T, Western Union, Tradeassurance
Delivery Time: 1-3 days (depend on order) Means of Transport: By Sea, Air or DHL/FEDEX/TNT/EMS
Guarantee: We will check and send detailed pictures to buyers for confirmation

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

Pos. Part No Qty Parts name Comments
1 095-0940 [1] RING-RETAINING (INTERNAL)
2 7X-1553 [1] SEAL-LIP TYPE
3 197-0074 [1] HOUSING
4 9S-8006 [2] PLUG (7/8-14-THD)
5 2M-9780 [2] SEAL-O-RING
6 197-0075 [1] RACE
7 197-0076 [1] BEARING
8 197-0077 [1] SHAFT
9 8U-9480 [2] PIN
10 197-0078 [2] BEARING
11 131-4647 [1] CRADLE
12 121-9915 [3] SLEEVE
13 197-0079 [9] PISTON AS
14 131-4649 [1] WASHER (61X123X5.5-MM THK)
15 197-0080 [1] PLATE
16 131-4657 [1] PLATE
17 8U-3297 M [4] BOLT (M10X1.5X25-MM)
18 286-1674 [1] BARREL GP-PUMP
19 197-0082 [1] WASHER (39.2X53.8X4-MM THK)
20 197-0083 [1] SPRING
21 197-0084 [1] RING
22 197-0085 [1] SPACER (41X46X19.2-MM THK)
23 195-6882 [1] RING
24 121-9943 [1] RING
25 197-0086 [1] SPACER (47X54X38-MM THK)
26 197-0087 [1] RING
27 197-0090 [1] PLATE
28 101-2862 [2] DOWEL
29 197-0088 [1] RING
30 197-0089 [1] BEARING
31 199-4193 B [1] KIT-SHIM (INCLUDES 21-SHIMS)
32 8C-3131 [2] SEAL-O-RING
33 121-9941 [2] RING
34 131-4674 [2] PIPE
35 131-4675 [1] RING
36 131-4676 [1] PISTON
37 284-3781 [1] PISTON
38 197-0093 [1] RETAINER
39 197-0094 [1] SPRING
40 288-1199 [1] RETAINER
41 284-3782 [1] PISTON
42 9T-4901 M [2] NUT (M12X1-THD)
43 121-9946 [2] PIN
44 3E-6910 M [9] BOLT-SOCKET HEAD (M12X1.75X70-MM)
45 117-8765 [1] SEAL-O-RING
46 8T-9384 [2] BOLT (1/2-13X0.875-IN)
47 195-6932 [1] COVER
48 227-3021 Y [1] VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)
49 285-8226 [1] HOUSING
50 8U-3875 [1] PLUG
51 5W-7461 B [1] SHIM (1.05-MM THK)
52 5W-7462 B [1] SHIM (1.1-MM THK)
53 5W-7463 B [1] SHIM (1.15-MM THK)
54 5W-7464 B [1] SHIM (1.25-MM THK)
55 5W-7465 B [1] SHIM (1.5-MM THK)
56 5W-7466 B [1] SHIM (1.75-MM THK)
57 131-4654 B [1] PLATE (0.05-MM THK)
58 131-4655 B [1] PLATE (0.075-MM THK)
59 131-4656 B [1] PLATE (0.1-MM THK)
60 131-4650 B [1] PLATE (0.05-MM THK)
61 131-4651 B [1] PLATE (0.075-MM THK)
62 131-4652 B [1] PLATE (0.1-MM THK)
63 6V-5192 M [3] BOLT-SOCKET HEAD (M8X1.25X30-MM)
64 285-5644 [1] RING-RETAINING
65 333-8366 [1] SEAL-SHAFT
66 333-8564 J [2] PLUG AS

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

162-0324 CA1620324 1620324 10R0862 For Cat D6R II TRACK-TYPE TRACTOR Hydraulic Pump Piston Pump MAIN PUMP Pump Assy Pump Assembly PUMP GP-PISTON Aftermarket Original

Why choose us?

1, Do you still find a company which can provide one-stop solution to your problem? Why not choose us?

2, Do you still find a company which could provide high-quality products with comparative price? How about choose us?

3, Do you still find a company which is glad to to take good service to make you feel at home? Why do not take us into consideration?

4, Do you have a high requirements for products, ant hope it could have large stock, short delivery time and long warranty period? Welcome to our company and choose products that meet your needs.

5, As a professional company in this industry, we have accurate data to follow the excavator brand part number inquiry, guarantees the product’s correct rate.You can trust us because we can find parts for nearly all your needs.
