Specifications
Brand Name :
DZ
Model Number :
DZ-003
Place of Origin :
China (Mainland)
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
50 sets per month
Delivery Time :
30-45 working days
Packaging Details :
wooden case
Flow test range :
Main circuit 15-600L/min 2 channels
Recovery pump sets :
The flow rate is 26L/min
Temperature :
Water cooling and heat dissipation
Control & Collection :
PLC control, computer acquisition
Description

Digital Hydraulic Piston Motor Testing Equipment, Plunger Motor Test Bench

Features

The hydraulic comprehensive test bench for production design and manufacture has complete functions, simple operation, compact structure, easy operation, hydraulic components for construction equipment, and necessary testing equipment for hydraulic pump, hydraulic motor, hydraulic valve and cylinder repair.

Technical Parameter

Total power
75KW,90KW,110KW,132KW,160KW,315kw,350kw
Range of test pressure
0~42MPa
Range of flow rate
0~500L/min
Range of rotational speed
0~3000r/min
Composition
Dynamic system, hydraulic control system, hydraulic oil filter temperature control system and electric control system, data acquisition test system
Applicable area
Apply to performance test of the hydraulic components that supported by a host in engineering machinery, metallurgical, petroleum, machinery, aerospace, shipbuilding and other fields.

Hydraulic pump test bench, hydraulic pump maintenance test bench for concrete equipment, hydraulic motor test bench, hydraulic valve test bench, hydraulic cylinder test bench, hydraulic comprehensive test bench, hydraulic component test bench,Hydraulic test bench, hydraulic pump repair test bench.


Pump test items

No. Testing project Remark
1 Displacement test The test curve is displayed
2 Volumetric efficiency test The test curve is displayed
3 Total efficiency test Displays the curves
4 Variable characterization test The test curve is displayed
5 Pump control valve setting Manual setting

Description of the main sensor configuration of the test system:

No Parameter Position/Function Measuring range and accuracy Remark
1 Primary loop traffic Measuring range 15-600L/min, measurement accuracy: ±0.5%, 2 sets of Hydrotechnik turbine flowmeters
2 Main pressure AB port 600 bar with 0.25% accuracy 5 sets of pressure sensors
3 Oil pressure control Pilot pump P port
250 bar, with 0.25% accuracy
4 Pilot and make-up oil pressure 100 bar, with 0.25% accuracy
5 Torque sensor 2000NM, ±0.2% accuracy
6 Temperature 150℃, with 0.5% accuracy
7 Electrically controlled PLC control system Siemens
8 Electrically controlled Industrial control acquisition system Nuojiada all-in-one machine

Digital Hydraulic Piston Motor Testing Equipment Plunger Motor Test Bench

Why choose us?


Changzhou Dazhuo Testing Equipment Co., Ltd has a number of system design, structural design, software design engineers, in the design and development, manufacturing, installation and commissioning of hydraulic test systems and sales services have a strong comprehensive strength. In recent years, the core team has successively supported Caterpillar, Italy OMFB, Bosch Rexroth (Lozon), SMS (SMS), Japan Shimadzu, Zhejiang Haihong, Shanghai Qiangtian and other well-known domestic and foreign host and hydraulic manufacturers, and has accumulated rich experience.

Hydraulic test bench, hydraulic test bench, hydraulic pump test bench, hydraulic pump maintenance test bench for concrete equipment, hydraulic motor test bench, hydraulic valve test bench, hydraulic cylinder test bench, hydraulic comprehensive test bench, hydraulic component test bench, hydraulic test bench, Hydraulic test bench, hydraulic pump repair test bench.

Advantage :Hydraulic test bench equipment features

1. Using the imported pneumatic pump from the United States as the pressure source, the pump hydraulic pump maintenance test bench, the test pressure is high, the output pressure can be adjusted steplessly, and the boost rate can be set freely;
2, using multi-pump supply pressure, the output flow is larger, the test range is wider, can meet the pressure test requirements from the range;
3. The hydraulic test bench adopts the control system and the hydraulic pump maintenance test bench. The whole test process can be completed on the computer. The computer automatically generates the pressure and time curve, and stores various data, and the test report can be printed at any time. The test process can also be manually controlled by a push button switch;
Widely Application:
Piston pumps are widely used in high-pressure, high-flow, high-power hydraulic systems and where flow adjustment is required, such as construction machinery, mining machinery, marine machinery, transportation handling machinery, and construction machinery.
