Specifications
Warranty :
1 YEAR
Customized support :
OEM
Place of Origin :
Beijing, China
Brand Name :
BGT
Model Number :
RD-600S
Product name :
radar flow meter
Key Word :
radar water flow meter
Power supply :
7-32V DC (5.5-32V DC optional)
Accuracy :
±0.01m/s
Output signal :
RS485 default
frequency :
24GHz
Maximum range :
7m
use temperature :
-20~+70℃
Material :
Aluminum shell
Protection level :
IP68
Certification :
CE
Packaging Details :
Box( radar water flow velocity sensor)
Price :
$1,970.22/pieces 1-9 pieces
MOQ :
1 piece
Description
Product Description

RD-600S 24GHz Open Channel 3 In 1 Non-contact 7m Measuring Range Radar Water Flow Velocity Flowmeter For Rivers

RD-600S radar flowmeter is a non-contact instrument which can measure water level, velocity and flow. During the measurement, the equipment is not affected by sewage corrosion, temperature and sediment; the civil engineering is simple, less affected by water damage, easy to maintain and ensure the safety of construction personnel. The RD-600S radar flowmeter uses microwave radar technology, which adopts precision planar narrow-band array radar sensor, digital signal floating-point algorithm processing, velocity direction identification, rain day denoising, vertical angle automatic correction and other functions; the equipment is easy to install, and can realize non-contact measurement of water level, velocity and flow of river, open channel, reservoir, sewage pipe network, etc.


RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
Data sheet
Measurement parameters
Radar
Product name
Radar Water Flowrate Water level water flow 3 in 1 meter
Flow measurement system
±0.03m/s
Measuring principle
Radar Planar microstrip array antenna CW + PCR
Operating mode
Manual, automatic, telemetry
Applicable environment
24 hours, rainy day
Operating temperature range
-30℃~+80℃
Operating Voltage
7-32V / 5.5-32V (optional) DC power supply
Relative humidity range
20%~80%
Storage temperature range
-30℃~80℃
Working current
4VDC input, working mode: ≤300mA standby mode
Lightning protection level
6KV
Physical dimension
160*100*80(mm)
Weight
1KG
Protection level
IP68
Radar Flowrate sensor
Flowrate Measuring range
0.03~20m/s
Flowrate Measurement accuracy
±0.01m/s ;±1%FS
Flowrate Radar frequency
24GHz
Radio wave emission angle
12°
Radio wave emission standard power
100mW
Measuring direction
Automatic recognition of water flow direction, built-in vertical angle correction
Radar Water level gauge
Water level Measuring range
0.2~7.0m
Water level Measuring accurancy
±2mm
Water level Radar frequency
60GHz
Radar power
10mW
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
Application
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
Related Products
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m




Open Channel Handheld Portable Lcd Display Radar Surface Water Flow Velocity Sensor For Water And Liquid Speed Measurement
1.The data can be transmitted wirelessly via blue-tooth (as optional blue-tooth);
2.RD-600S can be used continuously for more than 10 hours using built-in high capacity lithium ion battery,
3.a variety of charging ways, you can use alternating current, vehicular charging and mobile power charging.
Customer feedback
More than 30 good feedback from Alibaba Trade Assurance Order since 2018.
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
Company Profile

Beijing Guoxinhuayuan Technology Co.,Ltd is a Hi-tech company with R&D, production, marketing, project implementation and after sales. We are focus on providing professional hydrology and meteorology monitoring device and technical service, and developed a series of flood early warning system products by ourselves, which owning more than 50 patents and 60 software copyrights. Then our product line is including monitoring products, communication products, early warning products and cloud platform. However, our products have been sold to more than 30 countries, such as Australia, Japan, Sri Lanka and so on. Especially our tipping bucket rain gauge is doing well in foreign countries. Meanwhile, our products are covered all provinces in China and we have Guangxi/Guangdong/Hunan/Hubei/Qinhai branches.

We are devoted to solving the flood disaster problems for human beings and becoming one of the famous brands in the flood early-warning industry. Welcome to contact us.
Hot sale industrial universal water tank level pressure sensor
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
EXS&CES
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
RD-600S 24GHz Open Channel 3 in 1 Non-Contact Radar Water Flow Velocity Flowmeter 7m
Advantages& FAQ

Why Choose Us

◆8 years in hydrology and meteorology wireless communication industry
◆Apply in more than 50 countries & areas
◆Certificated completed
◆Millions of terminals on-line
◆Strong R&D team, senior staff more than 60
◆Support OEM/ODM cooperation


FAQ


Q1. Can I have a sample order ?
Hot sale industrial universal water tank level pressure sensor
A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.
Hot sale industrial universal water tank level pressure sensor
Q2. What about the lead time?
Hot sale industrial universal water tank level pressure sensor
A:Sample needs 3-5 days, mass production time needs 1-2 weeks.

Q3. Do you have any MOQ limit?
Hot sale industrial universal water tank level pressure sensor
A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Hot sale industrial universal water tank level pressure sensor
Q5. How to proceed an order ?

A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.

Q6. Is it OK to print my logo on the products?
Hot sale industrial universal water tank level pressure sensor
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.
Hot sale industrial universal water tank level pressure sensor
Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

Hot sale industrial universal water tank level pressure sensor
