CCC Air Cooled Chiller Meeting MD30D Water Cooling Machine Copeland Compressor
CCC Air Cooled Chiller Meeting MD30D Water Cooling Machine Copeland Compressor
CCC Air Cooled Chiller Meeting MD30D Water Cooling Machine Copeland Compressor
CCC Air Cooled Chiller Meeting MD30D Water Cooling Machine Copeland Compressor
Specifications
Brand Name :
Meeting
Model Number :
MD30D-5
Certification :
CE, ISO9001, CCC
Place of Origin :
Guangzhou China
MOQ :
5 PCS
Price :
Negotiation
Payment Terms :
T/T, L/C WESTERN UNION
Supply Ability :
800/MONTH
Delivery Time :
15 days
Packaging Details :
Plywooden case
Cooling capaicty :
7KW
Materail :
Spray sheet metal
Copper Pipe thick :
0.8mm - 1mm
Compressor :
Copeland
Outlet water temperature :
7 degree
Defrosting :
Automatically
Level of security :
1P×4
Description

Meeting MD30D Water Cooling Machine 7KW Water Chiller Copeland Compressor

Technology Specification

Rated input power: 2.98KW Rated outlet water temperature: 12℃
Rated cooling capacity: 7KW The lowest outlet water temperature: 7℃
Rated voltage: 220V/380V Super quiet Noise: ≤45Db
Rated frequency: 50HZ Water pipe of Interface: Internal thread (copper)
Rated current: 13A/6A Water flow: 3000L/H
Pipe size: DN25 Evaporator: Finned heat exchanger
Compressor: Copeland Condenser: Double pipe heat exchanger
Control System: Multi control Throttle units: Electronic expansion valve
Level of security: 1P×4 Electric shock protection grade: 1 grade
Dimensions: 1120*490*710mm Packing size: 1190*520*865mm


Remarks: The test conditions of above parameter: dry bulb temperature: 20℃, wet bulb temperature: 17℃, Initial water temperature 15℃, outlet water temperature 7 ℃.

Product details:

CCC Air Cooled Chiller Meeting MD30D Water Cooling Machine Copeland Compressor

A. Payment service

1. T/T (30% deposit, the balance paid before delivery)

2. L/C (for container order only)

B. Technical service

1. We calculate the capacity and recommend the best models.

2. We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.

3. We supply the spare parts and technical support in and after the warranty time.

4. We supply the training course to your workers at our factory if you need.

5. We can offer site training to your workers in your place which is negotiable.

C. After-sales service

1. Technical support for your installation, operation and maintenance.

2. Standard warranty time: One year warranty for heat pumps.

You can also pay for extended warranty or we can renegotiate the longer warranty period.

3. Spare parts and technical support at most economic prices after the warranty.

FAQ

Q1. Can I have a sample order for the Heat pump dryer?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: Sample needs 3-10days, mass production time depend on the products' quantity.

Q3.Do you offer guarantee for the products?

A: Yes, 12 months since the heat pump depart from the port of loading (Refer to the Bill of Lading).

Certificsate we have got :

  • ISO 9001, ISO 14000
  • Our company has been inspected and certificate by EMC
  • CE And EN14511, EN 14825-ERP for heat pump exported to Europe
  • Energy label for all heat pump models sold to oversea market
  • Testing laboratory calibrated by CNAS

Our Main products

Air to water heat pump , DC inverter heat pump, High water temperature heat pumps

Monoblock house heating heat pumps ,Split heat pump ,Super low noise heat pump

Water chiller,Ground source heat pump , water to water heat pump , swimming pool heat pump
