Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Specifications
Model NO. :
Customizable
Porosity :
55%-60%/35%-45%/45%-55%
Pore Size :
25-35/10-20/20-25um
Thickness :
1.0-2.0/0.25-0.35/0.2-1.0mm
Transport Package :
Wood Package
Specification :
Customizable
Trademark :
AEET
Origin :
China
HS Code :
8108903290
Supply Ability :
1000/30 Days
Material :
Titanium
Application :
Industry
Type :
Ti Filter
Filter Connector :
N/a
Filtration Grade :
ULPA Filter
Width :
up to 300mm
Customization :
Available | Customized Request
Place of Origin :
China
Brand Name :
AEET
Certification :
ISO9001:2015, ISO14001:2015
MOQ :
50
Price :
Negotiable
Packaging Details :
Wood Package
Delivery Time :
Peak Season Lead Time: one month, Off Season Lead Time: one month
Payment Terms :
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Description
Product Description

The Sintered Layer is a key material for the fuel cell and PEM electrolyzer, ensuring effective transmission of liquid and produced gas between the membrane electrode and bipolar plate.

Metal Powder > Forming > High-Temperature Sintering > Sintered Layer

Detailed Photos
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm

Product Parameters
Processing Technology Process 1 Process 2 Process 3
Material Ti Ti/SS/Superalloy Ti/SS
Width Up to 300mm Up to 300mm Up to 300mm
Length Customizable Customizable Customizable
Thickness 1.0~2.0mm 0.25-0.35mm 0.2-1.0mm
Pore size 25-35um 10-20um 20-25um
Porosity 55%~60% 35%-45% 45%-55%
Permeability >5.0E-04L/Pa*min*cm2 >5.0E-04L/Pa*min*cm2 >1.0E-0.3L/Pa*min*cm2
Company Profile

Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm

What We Do

- INDUSTRIAL FILTRATION & PURIFICATION - HYDROGEN ENERGY

Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm


• High-efficient & energy-saving porous metal filter elements.
• Reliable filtration & separation systems and solutions.

Our Advantages


Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
• Strong technological capability of powder metallurgy porous materials from the Central Iron and Steel Research Institute

• Provides the planar support and liquid permeability required for PEM under high-pressure conditions, satisfying the future development trend of PEM electrolyzers

• Stable and low contact resistance, enhancing the potential for PEM hydrogen production under high pressure with our
advanced techniques

Packaging & Shipping
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm
Fuel Cell and Pem Electrolyzer Titanium Sintered Ti Layer 1.0-2.0/0.25-0.35/0.2-1.0mm


FAQ

Q: Are you a trading company or manufacturer? Where are you? Can I visit you?
A: We are a factory locale, welcome to visit us at any time.

Q: How long is your delivery time?
A: General 3-7 days if the goods are in stock. According to quantity 7-35 days if the goods you asking for are out of stock.

Q: Do you provide samples? Is it free or extra?
A: Yes. we could offer the sample with a free charge you only need to pay the courier fee.

Q: What are your terms of payment?
A: T/T (with 30% in advance), L/C at sight. Western Union. Paypal

Q: Can you give a warranty on your products?
A: We extend a 100% satisfaction guarantee on all items. Please feel free to immediately feedback if you are dissatisfied with our quality or service. For overseas orders, we guarantee most accessories. Provide emails with details including pictures or a short video, we will send a guide manual or replacements at our cost to repair.
