3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
3.6g/Cm³ 95% Alumina Ceramics Ring High Insulation Heat Resistant
Specifications
Brand Name :
HENGYUAN
Model Number :
95% Alumina Ceramics
Certification :
CE,UL
Place of Origin :
WUXI JIANGSU CHINA
MOQ :
100
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000 PCS/WEEK
Delivery Time :
20 DAYS
Packaging Details :
Carton
Material :
95% Alumina Ceramics
Color :
White
Density :
3.6g/cm³
Working Temperature :
1600℃
OEM，ODM :
Acceptable
Orgin :
WUXI JIANGSU CHINA
MOQ :
100 PCS
Package :
Carton
Description

HENGYUAN manufactures and provides alumina ceramic components for a wide range of application like Mechanical Equipment, Electronic & Electrical, Oil Drilling, Medical, Chemical Industry etc. According to actual application and customer's requirement, the purities vary from 95%-99.7% and the forming methods will be different. The forming methods applied in our plant include dry pressing, isostatic pressing, injection moulding, extrusion moulding. With experienced engineers and talented workers, we are confident to offer high quality, high precision, complex components for customers worldwide.

Naterial Unit

A95%

Alumina Ceramics

A97%

Alumina Ceramics

A99%

Alumina Ceramics

A99.7%

Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardulus HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
*Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric constant εr 10 10 10 10
