Big Wideband Indoor Ceiling Antenna Vertical 698-3800 Mhz 6dBi 4G LTE
Big Wideband Indoor Ceiling Antenna Vertical 698-3800 Mhz 6dBi 4G LTE
Specifications
Brand Name :
ZD
Model Number :
ZD-MCA-738-4/5NF
Certification :
RoHS
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000pcs per month
Delivery Time :
3~4 weeks
Packaging Details :
Standard Packing
Name :
Indoor Ceiling Antenna
Frequency range :
698~3800
Polarization type :
Vertical
VSWR :
≤1.8
Gain (dBi) :
4±1
Isolation(dB) :
>20
Description

Big Wideband antenna 698-960mhz 1710 - 3800 MHz 6dBi Indoor 4G LTE WiFi Omni Directional Ceiling MIMO Antenna

To meet huge market demands, we are involved in presenting a wide assortment of Mimo Antennas, which are manufactured using high grade raw material sourced from certified and reputed vendors of the market. The products offered by our company are available in market at reasonable prices. MimoAntennas is widely uses in various industrial applications.

Item Name Specification
Frequency range (MHz) 698~960 1710~3800
Polarization type Vertical Vertical
VSWR ≤1.8 ≤1.8
Gain (dBi) 4±1 5±1
Isolation(dB) >20 >20
Horizontal Beamwidth (°) 360 360
Vertical Beamwidth (°) 85 50
Input impendence (Ω) 50Ω
Intermodulation (dBc)(2*33dBm) -153
Max power (W) 50
Connector type 2*N/N-female
Weight (g) 380
Dimension (mm) Φ208×55
Radome material Uv-Protected ABS
Antenna’s color White
Environment Temperature (℃)

Limit Temperature:

-55~+70

Working Temperature:

-40~+60

Big Wideband Indoor Ceiling Antenna Vertical 698-3800 Mhz 6dBi 4G LTEBig Wideband Indoor Ceiling Antenna Vertical 698-3800 Mhz 6dBi 4G LTE

Our Advantages:

1. We have our own R&D team and have 17 R&D engineers,with independent R&D lab,can quickly provide upmarket product customerization services for customers.
2. We have 6 passive components production lines,150 employees,adopt advanced automatic screw machine,production capacity can up to 5000PCS/ per day.
3. Owning full set of available testing equipment to guarantee the quality of products.
4. Adopt advanced ATE testing system,owning full frequency of Intermodulation test equipment,perfect ERP management system and blameless process quality control system to promise the high qualification rate.
5. Our factory have more than 8 years production experience on antenna and passive components,have a rich product category and high cost-effective,is the leader in antenna and the passive communications industry in China.
