Specifications
Brand Name :
ZD
Model Number :
ZD-OCA-740-2/5NF
Certification :
ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
standard packing
Frequency :
698-3800MHz
Gain :
2/5dBi
Connector :
N Female
VSWR :
≤1.5
Impedance :
50Ohm
Polarization :
Horizontal
PIM :
≤-150dBc
Description

New 5G Antenna 698-3800MHz full Band -150dBc indoor omni ceiling antenna 5G antenna

Electrical parameters
Frequency Range(MHz) 698-960 1710-3800
Gain(dBi) 1.0~1.5 2~5
Horizontal-3dB Beamwidth(°) ±1.5 ±1.0
Vertical-3dB Beamwidth(°) 105~85 65~35
VSWR ≤1.8
Input Impedance(Ω) 50
Polarization Vertical
Max Input Protection(W) 50
Intermodulation IM3(2X33dBm) ≤-150dBc
Connector N-Female
Lighting Protection DC Ground
Mechanical parameter
Antenna Dimension(mm) Φ186×85
Weight(kg) 0.4
Cover Material ABS
Operating Temperature(°) -40~+60
