Specifications
Place of Origin :
Shanghai, China
Brand Name :
ICEMA
Packaging Details :
wooden case/container
Supply Ability :
10Set/Sets per Month
Price :
$10,000.00/sets 1-1 sets
MOQ :
1 set
Delivery Time :
15-30 days
Model Number :
BMC-2T
Certification :
CE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Voltage :
380V
Warranty :
1.5 years
Core Components :
Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC
Compressor brand :
Emerson, Bristol, Other, Frascold, Xumei, Bitzer, Sanyo, Performer, TECUMSEH, Maneurop, hitachi, Copeland, Daikin, DORIN, Fusheng
Net weight(kg) :
1300
Ice tray number :
6pcs
Insulation material :
PU material
Refrigerant :
R404A
Ice Making Speed :
12-17 minutes / time
Ice size :
28mm,10kg/ 20kg/30kgs,40mm,D22/29/35mm or customized,Customer's Requirement
Description

Industrial 2T/24H Ice Maker Machine Ice Cube Maker Making Machine Farms/Manufacturing Plant/Factory Southeast Asia Afric

Feature
1. Sufficient output, up to 100% rated or more
2. Fully automatic control
3. The output can be customized, up to 10 tons
4. Customizable non-standard voltage
5. Ice tray size can be customized
6. Self-contained ice storage and ice delivery screw
7. Color touch screen + PLC control, the whole process can be monitored
8. Air and cold water cooling can be customiz
ed, the default water cooling
9. Environmentally friendly R404a refrigerant 10. Multiple compressor brands are optional

Machine Parameter

Model output
(kg)
voltage power (w) refrigerant ice size(L*W*Hmm) machine size(L*W*Hmm)
BMC-2T 2000 380v/3P/50/Hz 8.73kw R404A/R22 22*22*22 1500x1430x2070
BMC-3T 3000 380v/3P/50/Hz 15.45kw R404A/R22 22*22*22 1800x1430x2070
BMC-4T 4000 380v/3P/50/Hz 22.95kw R404A/R22 22*22*22 2100x1430x2070
BMC-5T 5000 380v/3P/50/Hz 27.75kw R404A/R22 22*22*22 2400x1430x2070

2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory

Output Compressor Power Power Supply Dimensions Refrigeration
2T/24H 10HP 380V3P50HZ 1500*1430*2070 R404a
3T/24H 15HP 380V3P50HZ 1800*1430*2070 R404a
4T/24H 20HP 380V3P50HZ 2100*1430*2070 R404a

2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory

2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory2T/24H Ice Cube Industrial Machine Farms / Manufacturing Plant / Factory

Products Feature

1. Sufficient output, up to 100% rated or more

2. Fully automatic control

3. The output can be customized, 1tons up to 10 tons

4. Customizable non-standard voltage

5. Ice tray size can be customized

6. Self-contained ice storage and ice delivery screw

7. Color touch screen + PLC control, the whole process can be monitored

8. Air and cold water cooling can be customized, the default water cooling

9. Environmentally friendly R404a refrigerant

10. Multiple compressor brands are optional

Shanghai ICEMA refrigeration technology co.,LTD is a technology-based enterprise that pay attention to user experience.According to customer requirements,Company can produce intermediate,low and ultra low temperature refrigeration system,covering cooling, keeping fresh,cold storing,freezing,quick freezing and other fields,our machines not only have a large market share in china,and also be exported to Southeast Asia, Africa, Middle East,South America,Europe and other countries.

According to the developing requirement of the market,SHANGHAI ICEMA refrigeration technology co., LTD has developed a group of standard machines for customers in all industries, including brine refrigeration block ice machine, direct refrigeration block ice machine (high quality aluminum plate), tube ice machine, seawater type flake ice machine, freshwater type flake ice machine, plate ice machine, slurry ice machine, cube ice machine, water chiller, rake ice storage, spiral ice storage, fruits,vegetables and meat cold storage,spiral ice feed system, etc.

We participate in promotion and industry exchange activities attentively. In the long-term development process, the company has established long-term good partnership with many customers at home and abroad with excellent product quality, good product performance, leading technology advantages, and the company leads customers to visit It is our most important business philosophy to ensure that customers are assured of products by establishing the factory's production base, various production machinery and equipment, and finished products.

Q1-What is the lifespan of the machine?

A1- It can be used for 8-10 years under normal circumstances. The machine should be installed in a well-ventilated environment without corrosive gases and liquids. Usually, pay attention to the cleaning of the machine.

Q2-What is your payment method?

A2-The most ideal payment method for us is T/T, but we also accept pre-T/T+L/C or 100% L/C at sight. You can also pay directly at the Alibaba background. We have several payment methods, which one do you think is more suitable for you?
