109P0424H6D14 PCB Connector Blowers FAN 40 X 20MM 24V DC Lock Ball Bearing
109P0424H6D14 PCB Connector Blowers FAN 40 X 20MM 24V DC Lock Ball Bearing
109P0424H6D14 PCB Connector Blowers FAN 40 X 20MM 24V DC Lock Ball Bearing
109P0424H6D14 PCB Connector Blowers FAN 40 X 20MM 24V DC Lock Ball Bearing
Specifications
Brand Name :
Sanyo Denki
Model Number :
109P0424H6D14
Place of Origin :
JAPAN
MOQ :
1 PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union ,paypal
Supply Ability :
10000
Delivery Time :
3-5days
Packaging Details :
BOX
Categories :
DC Fans
Voltage - Rated :
24V
Air Flow :
8.2 CFM (0.230m³/min)
Static Pressure :
0.280 in H2O (69.7 Pa)
Bearing Type :
Ball
Noise :
35.0 dB(A)
Power (Watts) :
1.68W
Size :
40*40MM
Description

109P0424H6D14 PCB Connector Blowers FAN 40X20MM 24VDC LOCK

General Specifications

・ Material ………………………Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-1)

・ Expected life …………………See the table below. (L10 life: 90% survival rate for continuous operation in free air at 60˚C, rated voltage)

・ Motor protection function ………………… Locked rotor burnout protection, Reverse polarity protection For details, please refer to p. 529.

・ Dielectric strength …………………………… 50/60 Hz, 500 VAC, for 1 minute (between lead wire conductors and frame)

・ Insulation resistance ………………………… 10 MΩ or more with a 500 VDC megger (between lead wire conductors and frame)

・ Sound pressure level (SPL) ……………… At 1 m away from the air inlet

・ Storage temperature ……………………… -30 to +70˚C (Non-condensing)

・ Lead wire ……………………………………… Red Black or Blue Sensor Yellow

・ Mass ……………………………………………… 45 g

Description:

Muti-Port RJ45 side entry Network Jack with shield

Number of ports: 1*1

Number of position: 8

Number of contacts: 2,4,6 or 8
Electrical:

Rated current: 1.5A

Rated voltage: 125VAC

Insulation resistance: 500MΩmin

Contact resistance: 30MΩmax

Withstanding voltage: 1000VAC RMS, 50 or 60Hz 1 Min
Materials:

Housing: ABS resin (UL94V-0), PBT (UL94V-0), PA66 (UL94V-0), and PA46 (UL94V-0)

2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over Nickel

3. Shield: 0.20~0.25mm thickness brass with tin plated

4. Gold Plating: Fu",+3u",6u",15u",30u",50u"

Product Attributes Select All
Categories Fans, Thermal Management
　 DC Fans
Manufacturer Sanyo Denki America Inc.
Series San Ace 40
Part Status Active
Voltage - Rated 24VDC
Size / Dimension Square - 40mm L x 40mm H
Width 20.00mm
Air Flow 8.2 CFM (0.230m³/min)
Static Pressure 0.280 in H2O (69.7 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Features Locked Rotor Sensor
Noise 35.0 dB(A)
Power (Watts) 1.68W
RPM 8300 RPM
Termination 3 Wire Leads
Operating Temperature -4 ~ 158°F (-20 ~ 70°C)
Approvals CSA, TUV, UL
Weight 0.099 lb (44.91g)
Current Rating 0.070A
Voltage Range 12 ~ 27.6VDC
