DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
Specifications
Brand Name :
DELI
Model Number :
DL136HT-XX-10.16
Place of Origin :
CN
MOQ :
1pcs sample order
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
10000
Delivery Time :
3-5days
Packaging Details :
stardard packing
Price :
negotiation
Pitch :
10.16MM
Poles :
1P-XXP
Screw :
M4、Steel、Zinc plated、Brass、Ni plated
Rated voltage :
750V/1000V
Rated current :
57A/65A
Withstanding voltage :
AC3000V/1Min
Wire range :
20-6AWG
Description

DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A

with UL CE

MATERIAL
Pitch: 10.16MM
Poles: 1P-XXP
Screw: M4, Steel, Zinc plated, Brass, Ni plated
Wire cage:
 Brass, Ni plated
Pin header: Brass, Tin plated
Housing: PA66. UL94V-0

ELECTRICAL
Rated voltage:
 750V/1000V
Rated current:
 57A/65A
Withstanding voltage:
 AC3000V/1Min
Wire range: 20-6AWG

MECHANICAL
Temperature range:
 -40℃-- +105℃
MAX soldering:
 +250℃ for 5 sec
Torque:
 1.2Nm(10.6 lb.in)
Strip length:
 10mm

DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
DL136HT-XX-10.16mm pitch plastic screw terminal block with 750V / 57A with UL CE
Deli electronics tehcnology co ltd
www.icmemorychip.com
www.deli-ic.com(updating)
Email:sales3@deli-ic.com
Skype:hkdeli881
Sales: VIVI
