Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
Specifications
Brand Name :
DELI
Model Number :
DL134C-XX-10.16
Place of Origin :
CN
MOQ :
1 pcs sample order
Payment Terms :
T/T, Western Union, paypal
Supply Ability :
10000
Delivery Time :
3-5days
Packaging Details :
standard packing
Price :
negotiation
Pitch :
10.16MM
Poles :
1P--xxP
Screw :
M4、Steel、Zinc plated
Housing :
PA66. UL94V-0
Rated voltage :
600VV/750V
Rated current :
60A/57A
Withstanding voltage :
AC3000V/1Min
Wire range :
20-6AWG/10M ㎡
Pin header :
Brass , Tin plated
Description
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
MATERIAL
Poles: 1P--xxP
Screw: M4, Steel,Zinc plated
Wire cage: Brass, Ni plated
Pin header: Brass,Tin plated
Housing: Housing:PA66. UL94V-0


ELECTRICAL
Rated voltage: 600VV/750V
Rated current: 60A/57A
Withstanding voltage: AC3000V/1Min
Wire range: 20-6AWG/10M ㎡

MECHANICAL
Temperature range: -40℃-- +105℃
MAX soldering: +250℃ for 5 sec
Torque:
1.2Nm(10.5 lb.in)
Strip length: 10mm
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16

Deli electronics tehcnology Co., Ltd.
www.icmemorychip.com

www.deli-ic.com
Email:sales3@deli-ic.com
Skype:hkdeli881
Sales: VIVI
