THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
THD10-2423WIN 15V 10W DC Converter Isolated Module 9 Leads 24-DIP
Specifications
Brand Name :
TRACO POWER
Model Number :
THD10-2423WIN
Certification :
CE/ RoHS
Place of Origin :
Swiss
MOQ :
5-10pcs
Price :
To be negotiated
Payment Terms :
T/T, Western Union ,paypal
Supply Ability :
10,000PCS
Delivery Time :
in stock 2-3days
Packaging Details :
standard safe package polybag and carton
PN :
THD10-2423WIN
Brand :
TRACO POWER
Original :
Swiss
Converter :
DC-DC Converter
Power :
10W
Type :
Isolated Module
Description

THD10-2423WIN# Isolated Module DC-DC Converter +/- 15V 10W Module 9 Leads 24-DIP

Voltage - Input (Min) 9V
Size / Dimension 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Power (Watts) 10W
Voltage - Output 1 15V
Applications ITE (Commercial)
Packaging Tube
Features Remote On/Off, OCP, SCP
Voltage - Output 4 -
Type Isolated Module
Series THD 10WIN (10W)
Voltage - Isolation 1.5kV
Supplier Device Package -
Manufacturer Traco Power
Mounting Type Through Hole
Part Status Active
Current - Output (Max) 333mA, 333mA
Efficiency 87%
Operating Temperature -40°C ~ 85°C (With Derating)
Package / Case 24-DIP Module, 9 Leads
Number of Outputs 2
Voltage - Output 3 -
Voltage - Input (Max) 36V
Voltage - Output 2 -15V

Features
◆ UItra wide 4:1 input voltage range
◆ Internal EMI-filter meets EN 55022, class A without external components
◆ High efficiency up to 87%
◆ Operating temperature range –40°C to +85°C
◆ No minimum load required
◆ I / O isolation 1’500 VDC
◆ Overload protection
◆ 3-year product warranty
The THD 10WIN series is designed for an optimized cost / performance ratio of
DC/DC converters with output power of 10 Watt.
They come with an internal EMI-filter to meet EN55022, class A without external components.
General features like no minimum load requirement, overload protection and high efficiency
make these converters easy to design in. With the popular DIP-24 standard package
they are also a drop in replacement for many cost critical applications.
