DL127S-XX-5.0/5.08mm 2 pins pcb screw terminal block connectors 300v
DL127S-XX-5.0/5.08mm 2 pins pcb screw terminal block connectors 300v
DL127S-XX-5.0/5.08mm 2 pins pcb screw terminal block connectors 300v
DL127S-XX-5.0/5.08mm 2 pins pcb screw terminal block connectors 300v
Specifications
Brand Name :
DELI
Model Number :
DL127S-XX-5.0/5.08
Place of Origin :
CN
MOQ :
100
Payment Terms :
T/T, Western Union
Supply Ability :
10000
Delivery Time :
2DAYS
Packaging Details :
BAG
Pitch :
5.0/5.08 MM
Poles :
2—24P
Screw :
M2.5、Steel、Zinc plated
Housing :
PA66. UL94V-0
Rated voltage :
250V/300V
Rated current :
15A/12A
Withstanding voltage :
AC2000V/1Min
Wire range :
26-16AWG
Description
MATERIAL
Pitch:5.0/5.08 MM
Poles: 2—24P
Screw:M2.5,Steel,Zinc plated
Wire cage:Brass,Ni plated
Pin header:Brass, Tin plated
Housing:PA66. UL94V-0
ELECTRICAL
Rated voltage:250V/300V
Rated current:15A/12A
Withstanding voltage:AC2000V/1Min
Wire range:26-16AWG
MECHANICAL
Temperature range:-40℃-- +105℃
MAX soldering:+250℃ for 5 sec
Torque:0.4Nm(3.5 lb.in)
Strip length:7mm
DL127S-XX-5.0/5.08mm 2 pins pcb screw terminal block connectors 300v
