Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96
Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96
Specifications
Brand Name :
DELI
Model Number :
DL350R-XX-3.5/3.96
Place of Origin :
CN
MOQ :
100
Payment Terms :
T/T, Western Union
Supply Ability :
10000
Delivery Time :
2DAYS
Packaging Details :
BAG
Pitch :
3.5/3.96MM
Poles :
2P、3P
Screw :
M2、Steel、Zinc plated
Housing :
PA66. UL94V-0
Rated voltage :
130V/300V
Rated current :
10A
Withstanding voltage :
AC1250V/1Min
Wire range :
24-18AWG
Description
MATERIAL
Pitch:3.5/3.96MM
Poles: 2P,3P
Screw:M2, Steel, Zinc plated
Wire guard: phosphor bronze, Ni platedor stainless steel
Pin header:Brass,Tin plated
Housing:PA66. UL94V-0
ELECTRICAL
Rated voltage:130V/300V
Rated current:10A
Withstanding voltage:AC1250V/1Min
Wire range:24-18AWG
MECHANICAL
Temperature range:-40℃-- +105℃
MAX soldering:+250℃ for 5 sec
Torque:0.2Nm(1.8 lb.in)
Strip length:4.5-5mm
Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96
DeLi Electronics Technology Co., Ltd
PART# : DL350R-XX-3.5/3.96
