5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
Specifications
Brand Name :
DELI
Model Number :
DL332K-XX-5.0
Place of Origin :
CN
MOQ :
100
Payment Terms :
T/T, Western Union
Supply Ability :
10000
Delivery Time :
2DAYS
Packaging Details :
BAG
Pitch :
5.0MM
Poles :
2P、3P
Screw :
M2.5、Steel、Zinc plated
Housing :
PBT. UL94V-0
Rated voltage :
300V/250V
Rated current :
10A/17A
Withstanding voltage :
AC2000V/1Min
Wire range :
24-14AWG
Description
MATERIAL
Pitch:5.0MM
Poles: 2P,3P
Screw:M2.5,Steel, Zinc plated
Wire cage:Steel, Zinc plated
Wire guard: phosphor bronze, Ni plated
Housing:PBT. UL94V-0
ELECTRICAL
Rated voltage:300V/250V
Rated current:10A/17A
Withstanding voltage:AC2000V/1Min
Wire range:24-14AWG
MECHANICAL
Temperature range:-30℃-- +120℃
MAX soldering:+250℃ for 5 sec
Torque:0.4Nm(3.5 lb.in)
Strip length:4.5mm
5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
