PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5
PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5
PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5
PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5
Specifications
Brand Name :
DELI
Model Number :
DL105R-XX-5.0/7.5
Place of Origin :
CN
MOQ :
100
Supply Ability :
10000
Delivery Time :
2DAYS
Packaging Details :
BAG
Pitch :
5.0/7.5MM
Poles :
1P-xxP
Screw :
M2.5、Steel、Zinc plated
Rated voltage :
250V/300V/450V
Rated current :
24A
Withstanding voltage :
AC2000V/1Min
Wire range :
24-14AWG/10mm
Description
MATERIAL
Pitch:5.0/7.5MM
Poles: 1P-xxP
Screw:M2.5,Steel, Zinc plated
Wire cage: Steel, Zinc plated
Pin header: Brass, Tin plated
Housing:PA66. UL94V-0
ELECTRICAL
Rated voltage:250V/300V/450V
Rated current:24A
Withstanding voltage:AC2000V/1Min
Wire range:24-14AWG/10mm
MECHANICAL
Temperature range:-40℃-- +105℃
MAX soldering:+250℃ for 5 sec
Torque:0.4Nm(3.5 lb.in)
Strip length:9mm
PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5PCB Mount Screw Terminal Block Connector 5.0mm 7.5 Pitch DL105R-XX-5.0/7.5
DeLi Electronics Technology Co., Ltd
PART# :DL105R-XX-5.0/7.5
