DL141AR-XX-2.5 150V 2A PCB Spring Connecting Brass Terminal Block 2.5mm
DL141AR-XX-2.5 150V 2A PCB Spring Connecting Brass Terminal Block 2.5mm
DL141AR-XX-2.5 150V 2A PCB Spring Connecting Brass Terminal Block 2.5mm
DL141AR-XX-2.5 150V 2A PCB Spring Connecting Brass Terminal Block 2.5mm
Specifications
Brand Name :
DELI
Model Number :
DL141AR-XX-2.5
Place of Origin :
CN
MOQ :
100
Payment Terms :
T/T, Western Union
Supply Ability :
10000
Delivery Time :
2DAYS
Packaging Details :
BAG
Pitch :
2.5MM
Poles :
1P-xxP
Housing :
PA66. UL94V-0
Contact :
Brass 、Tin plated
Rated voltage :
150V/130V
Rated current :
2A/6A
Withstanding voltage :
AC1250V/1Min
Wire range :
26-20AWG
Description
MATERIAL
Pitch:2.5MM
Poles: 1P-xxP
Contact:Brass , Tin plated
Clips:Stainless Steel
Housing:PA66. UL94V-0
ELECTRICAL
Rated voltage:150V/130V
Rated current:2A/6A
Withstanding voltage:AC1250V/1Min
Wire range:26-20AWG
MECHANICAL
Temperature range:-40℃-- +105℃
MAX soldering:+250℃ for 5 sec
Strip length:10mm
DL141AR-XX-2.5 150V 2A PCB Spring Connecting Brass Terminal Block 2.5mm
DeLi Electronics Technology Co., Ltd
PART# :DL141AR-XX-2.5
