Part number TPS389033QDSERQ1 is manufactured by TI Company and distributed by AYE. As one of the leading distributors of electronic products, we carry many electronic components from the world's top manufacturers.

For more information on TPS389033QDSERQ1 detailed specifications, quotations, lead times, payment terms and more, please do not hesitate to contact us. In order to process your enquiry, please add the quantity to your message.

Product details/Parameters

The TPS3890-Q1 is a high-precision voltage supervisor with low quiescent current that monitors system voltages as low as 1.15V and issues an open-drain RESET signal when the SENSE voltage drops below a preset threshold or the manual reset (MR) pin drops to a logic low. The RESET output remains low for a user-adjustable delay time after the SENSE voltage and manual reset (MR) return above the respective thresholds. The TPS3890-Q1 family uses a high-precision voltage reference to achieve 1% threshold accuracy. The user can adjust the reset delay time from 25μs to 30s by connecting the CT pin to an external capacitor. The TPS3890-Q1 has an extremely low quiescent current of 2.1μA and a small 1.5mm×1.5mm package, making it an excellent device for powering battery-powered and space-constrained applications. The device is rated for operation over the -40°C to +125°C (TJ) temperature range.

advantages

1. Parts source determine price, The source of our parts is very initial.

2. Price can be negotiable based on quantity; delivery terms;

3. We will try to help customers to reduce freight charge.

4. The price of products changes frequently, if you need to quote price, please inform the model which you need,we will give you the reasonable price as the standard quoted price in the same day
