37 Position High Density Connectors , Female Power Socket Connector Receptacle
37 Position High Density Connectors , Female Power Socket Connector Receptacle
Specifications
Brand Name :
Amphenol
Model Number :
NFD17C37SB4E1CA
MOQ :
50pcs
Price :
Negotiable
Supply Ability :
1000000pcs
Connector Style :
D-Sub
Connector Type :
Receptacle, Female Sockets
Number of Positions :
37
Number of Rows :
2
Shell Size, Connector Layout :
4 (DC, C)
Flange Feature :
Housing/Shell (4-40)
Description

NFD17C37SB4E1CA 37 Position D-Sub Receptacle, Female Sockets Connector

Amphenol Commercial NFD17 D-Sub High-Density Connectors

Amphenol Commercial NFD17 D-Sub High-Density Connectors offer 20mΩ contact resistance, 3A current rating, and 250VAC voltage. These connectors are available with either right-angle or vertical orientations and have 9 to 37 positions. The NFD17 series features glass-filled thermoplastic insulator construction with a UL 94V-0 flammability rating and contacts that come in copper alloy, brass, or phosphor bronze. Amphenol Commercial NFD17 D-Sub High-Density Connectors have a 1000MΩ insulation resistance at 500VDC and 1000VAC/rms 60Hz dielectric withstanding voltage.

SPECIFICATIONS

  • 20mΩ contact resistance
  • 3A current rating
  • 250VAC voltage
  • 9 to 37 positions
  • Right-angle or vertical orientations
Product Attribute Attribute Value
Amphenol
Product Category: D-Sub Standard Connectors
RoHS: Details
7 Position
Screw
Flange Mount
Vertical
Socket
Receptacle
Steel
Tin
Brand: Amphenol
Product Type: D-Sub Connectors - Standard Density
Subcategory: D-Sub Connectors
Voltage Rating: 250 V
  • Glass-filled thermoplastic insulator
  • Copper alloy, brass, or phosphor bronze contacts
  • 1000MΩ insulation resistance at 500VDC
  • 1000VAC/rms 60Hz dielectric withstanding voltage
