AD009-01T Infrared Remote Control OTP MCU IC Suitable For Various Infrared Remote Control Product

AD009 Infrared remote control IC OTP MCU mainly suitable for various infrared remote control products in a single format

AD009-01T:

AD009-01T SOP16 package, is a 4-bit RISC instruction microcontroller, built-in RC oscillation and infrared emission drive circuit, including 0.6K * 12bits PROM, 12 I/O ports. support up to 91 buttons, mainly suitable for various infrared remote control products in a single format

Features :

Low operating voltage 1.8V~3.6V

Low power consumption, standby current: T-type keyboard <3uA, M-type <1uA (VDD=3.0V)

0.6K*12 bit OTP ROM, 32*4 bit SRAM

12 I/O ports, 1 8-bit timer

Built-in RC oscillator

Frequency deviation≤±2.0% (voltage 1.8~3.6V, temperature -20~70℃)

Built-in IR LED driver circuit

l IOL=210mA @VDD=3V &VOL=0.3V

Built-in reset circuit power-on reset, low-voltage reset, WDT reset

AD009-08 :

Description
AD009-08 is a small-capacity single-chip microcomputer with infrared remote control. It can save crystal oscillator, triode, and capacitor. It is packaged in SOP16 and supports up to 91 buttons. It is mainly used for the development of a single infrared remote control product.

Features :

Working voltage 1.8V~3.6V
CMOS circuit, low power consumption, standby current <3uA
12 common I/O ports
Built-in RC oscillator
Frequency offset≤±1.2%.typ@VDD=1.8V~3.6V,T=25℃
u Built-in IR LED driver circuit
Drive current IOL=210mA .typ@VDD=3V &VOL=0.3V
u Built-in power-on reset, low-voltage reset, WDT reset

AD009-041:

AD009-041 is a 4-bit OTP microcontroller dedicated to infrared remote control, including 2K*12bits ROM, 32*4bits SRAM, built-in RC oscillation and infrared emission drive circuit, using SOP16 package, can support 66 key inputs, less peripheral components , stable quality and performance, mainly suitable for the development of infrared remote control products in the high-end market.

Features:
Working voltage 1.8V~3.6V
Built-in oscillation frequency deviation at room temperature ≤±1.0%
-20℃~70℃ Frequency deviation≤2.0%
Built-in IR LED driver circuit
Drive current 240mA@VDD=3.0V&Vol=0.3V.
10 common I/O ports + 1 input port
Standby current about 1uA
1 8-bit timer
Carrier frequency, duty cycle can be adjusted arbitrarily
Built-in power-on reset, low-voltage reset, WDT reset circuit
SRAM has power-down protection function
