G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
G6KU-2P-Y OMRON Signal Relay G6K Latching Single Coil DPDT G6K-2F-Y G5Q-14 D2F-01F
Specifications
Brand Name :
OMRON Corporation
Model Number :
G6KU-2P-Y DC3 BY OMZ
Certification :
ROHS
Place of Origin :
Japan
MOQ :
10pieces
Price :
Negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
50000pcs
Delivery Time :
3-10days
Packaging Details :
box
Category :
Electromechanical relay-Electronic Components
Production Name :
Signal Relay, G6K Series, Latching Single Coil, DPDT, Through Hole, 1 A, 3 VDC
Description :
Signal Relay 12VDC 1A DPDT(10x6.5x5)mm THT
Contact Arrangement :
DPDT
Series :
G6K
Termination Style :
Single Coil
Relay Construction :
Latching
Mounting :
Surface mounting
Operating Temperature (°C) :
-40-85(°C)
Demeasion :
(10x6.5x5)mm
Stock :
In Stock
Description

Electromechanical Relay Signal Relay G6KU-2P-Y OMRON Signal Relay G6K Series Latching Single Coil DPDT Through Hole

Angel Technology Electronics Co

Applications:

• Telecommunication equipment

• Office automation machines

• Test and measurement equipment

• Building automation equipment

• Security equipment

• Industrial equipment

• Amusement equipment • Home appliances

Surface Mounting Relay with the World’s Smallest Mounting Area

• Subminiature model as small as 5.2 (H) × 6.5 (W) × 10 (L) mm is ideal for high-density mounting (G6K(U)-2F(-Y)).

• Low profile of 5.2 mm improves mounting efficiency (G6K(U)-2F(-Y)).

• Light weight of 0.7 g contributes to higher speed mounting.

• Surface mounting terminal models incorporate a unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering.

• Ensures a dielectric strength of 1,500 VAC and conforms to FCC Part 68 (i.e., withstanding an impulse withstand voltage of 1,500 V for 10 × 160 μs).

• -Y models offer an impulse withstand voltage of 2,500 V for 2 × 10 μs (conforms to Telcordia specifications) by optimizing the distance between coil and contacts.

• Standard model conforms to UL/CSA standards, certified by BSI (EN62368-1).

• Models available with a 2.54-mm terminal pitch. • Rated carry current: 2A.

Category
Relays
　
Signal Relays, Up to 2 Amps
Mfr
Omron Electronics Inc-EMC Div
Series
G6K
Package
Tube
Product Status
Active
Mounting Type
Through Hole
Coil Voltage
3VDC
Contact Form
DPDT (2 Form C)
Contact Rating (Current)
1 A
Switching Voltage
125VAC, 60VDC - Max
Coil Current
33 mA
Coil Type
Latching, Single Coil
Features
-
Termination Style
PC Pin
Seal Rating
Sealed - Fully
Coil Insulation
-
Must Operate Voltage
2.25 VDC
Must Release Voltage
-
Operate Time
3 ms
Release Time
3 ms
Operating Temperature
-40°C ~ 70°C
Contact Material
Silver (Ag), Gold (Au)
Relay Type
Telecom
Coil Resistance
91 Ohms
Base Product Number
G6K

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHS Status RoHS Compliant
Moisture Sensitivity Level (MSL) 4 (72 Hours)
ECCN EAR99
HTSUS

8536.41.0020
