Specifications
Place of Origin :
China
Brand Name :
HongCe
Certification :
TUV、ITS、CSA、BV、SGS 、CNAS
Model Number :
SN-1
MOQ :
1 set
Price :
Negotiation
Packaging Details :
Plastic Tool Box
Delivery Time :
7 days
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100 sets/ month
IP Rating :
IPX3 IPX4
Material :
Brass
Water Flow :
10L/min±5%
Hole Diameter :
Ф0.5mm
Description

Portable Safety Ingress Protection Test Equipment IPX3 / IPX4 Handheld Spray Nozzle

Product information:

The spray nozzle is designed and manufactured in accordance with IEC60529 clause IPX3 and IPX4. It is used for the waterproof test of the electric appliance. Some parts of the enclosure can not be wet by the oscillating tube. Under this circumstance, the handheld spray nozzle is used by manual.

The difference between IPX3 and IPX4 is that the baffle should be removed in the IPX4 test.

Technical parameters:

No.

Item

parameter

1

Water supply

Water flow rate is 50～150kpa clean water without inclusion.

2

Spray nozzle parameters

external diameter: Ф102mM

spherical diameter: SФ75.5mm

There is a middle hole and There are 24 holes in the internal circle of holes of which the included angle is 30°. There are 96 holes in the external circle of holes of which the included angle is 15°. 121 holes in total.

The hole diameter: Ф0.5mm

It is made of brass.

3

Water flow

10L/min±5%,Flow meter is adjustable

4

Range of pressure gauge

0～0.4Mpa

5

Baffle

removable

6

Pressure gauge

0~0.25MPa

7

Site requirements

Dedicated IP waterproof test room,The ground should be flat with illumination

With good function of inflow and drainage. Wall installation

Picture view:

Portable Ingress Protection Test Equipment Handheld Spray Nozzle IPX3 IPX4

Portable Ingress Protection Test Equipment Handheld Spray Nozzle IPX3 IPX4
