Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
Specifications
Brand Name :
HongCe
Model Number :
HJ0617
Certification :
calibration certificate (cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
T/T
Supply Ability :
10 set /month
Delivery Time :
30 days
Packaging Details :
plywood
Warranty :
1 Year
Product name :
Current-Carrying Hoses Torsion Resistance Tester
Usage :
Torsion Resistance Test
Test Sample :
Current-Carrying Hoses
Standard :
IEC60335-2-2
Working station :
1 station
Bending speed :
10r/min, can be preset
Positive / inverse times :
5 times
Description

Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test

Standard of Home Appliance Testing Equipment:

IEC60335-2-2 Household and similar electrical appliances – Safety – Part 2-2: Particular requirements for vacuum cleaners and water-suction cleaning appliances clauseclause 21.104.

Application of Home Appliance Testing Equipment:

It is used to test whether the Current-carrying hoses is resistant to torsion.

Test sample of Current-carrying hoses Torsion Resistance tester:

Vacuum cleaner hoses, water suction type cleaning apparatus tube, washing machine water pipe.

Feature of Home Appliance Testing Equipment:

Adopt bending machine mode, use PLC control, touch screen operation, torsion times and torsion speed can be preset, it can automatic reverse and automatic shutdown when reaching to the test times.

One end of the hose is held in a horizontal position with the remainder of the hose freely suspended. The free end is rotated in cycles, each cycle consisting of five turns in one direction and five turns in the opposite direction, at a rate of 10 turns per minute.
The test is carried out for 2 000 cycles.

Parameters:

Power supply AC220V 50Hz.
Control and operation PLC intelligent electrical control, touch screen operation
Working station 1 station, multi-station can be customizable
Bending speed 10r/min, can be preset
Positive / inverse times 5 times
Test cycle 0-999999, can be preset,default 2000 times
Size and weight 1000×500×1000mm,100kg

Standard figure:

Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test

Home Appliance Testing Equipment Carrying Hoses Torsion Resistance Test
