IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
IPX3 / IPX4 IP Testing Equipment With Waterproof Handheld Test Device For Splash And Spray Resistance
Specifications
Brand Name :
HongCe
Model Number :
HH0803
Certification :
calibration certificate(cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
T/T
Supply Ability :
20 set per month
Delivery Time :
3 working days
Packaging Details :
Carton box
Standard :
IEC 60529
Product attribute :
IP Testing Equipment
Application :
IPX3 and IPX4
Characteristic :
1 hole at the centrExternal diametere
Pressure :
50～150Kpa
Nozzle material :
Brass
Spherical diameter :
SФ75.5mm
test duration :
5 min
Description

IPX3/IPX4 IP Testing Equipment with Waterproof Handheld Test Device for Splash and Spray Resistance

Product brief introduction for IP Testing Equipment:

This is a handheld test unit designed for testing IPX3/IPX4 water resistance levels. It simulates drenching and splashing environments to help you evaluate the water resistance of your equipment. This device is easy to operate and carry, making it ideal for laboratory and field testing.

Conditions when using the spray nozzle for IP Testing Equipment:

Test for second characteristic numeral 3 with spray nozzle

The counterbalanced shield is in place for this test.
The water pressure is adjusted to give the specified delivery rate. The pressure to achieve this delivery rate will be in the range of 50 kPa to 1 50 kPa. It should be kept constant during the test.
The test duration is 1 min/m 2 of the calculated surface area of the enclosure (excluding any mounting surface), with a minimum duration of 5 min.

Test for second characteristic numeral 4 with spray nozzle

The counterbalanced shield is removed from the spray nozzle and the enclosure is sprayed from all practicable directions.

The test duration is 1 min/m 2 of the calculated surface area of the enclosure (excluding any mounting surface), with a minimum duration of 5 min.

Standard for IP Testing Equipment:

IEC60529 degree of protection provided by enclosures (IP Code) of the IPX3 and IPX4

Feature:

Used for carrying out the IPX/4 water ingress protection test on specimens which can’t be thoroughly wet using the swivel tube.

The spray nozzle is made of brass and 304 stainless steel.

Full manual control enables you to wet every part of the enclosure under test.

The nozzle contains 121 holes with a diameter of 0.5 mm.

The required pressure is from 50 kPa to 150 kPa.

Comes with a pressure gauge and ball valve, and an electronic flowmeter is allowed to be added if required.

The shield shall be in place for the IPX3 test and be removed from the spherical area for the IPX4 test.

.

Parameters for IP Testing Equipment:

Item Parameter
Water supply Water flow rate is ＞10L/min±5%, pressure is 50～150kpa clean water without inclusion.
Spray nozzle parameters

External diameter: Ф102mm

spherical diameter: SФ75.5mm

121 holes of Ф0.5mm;

1 hole at the centre

1 inner circles of 12 holes at 30°pitch

4 outer circles of 24 holes at 15°pitch

Moving shield-Aluminum

Spray nozzle-Brass
Water flow 10L/min±5%,Flow meter is adjustable
Pressure gauge 50～150Kpa,Range of pressure gauge 0～0.25Mpa
Baffle Removable
Site requirements

Dedicated IP waterproof test room,The ground should be flat with illumination

With good function of inflow and drainage.
Testing time Manual control, at least 5min
