IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
Specifications
Brand Name :
HongCe
Model Number :
HCMP50
Certification :
calibration certificate (cost additional)
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
T/T
Supply Ability :
1 set /month
Delivery Time :
45 days
Packaging Details :
plywood
Product name :
Motor Performance Test System
Standard :
IEC 60034-1
application :
perform the performance characteristics of motor
test benchs :
2
test stations :
3
test samples :
Single-phase motor, 3-phase motor
Dynamometer :
1.7 N.m, 6.2 N.m and 50 N.m
testing methods :
Manual And Automatic
Description

IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing

Standard:

IEC 60034-1 Rotating electrical machines-Part 1: Rating and performance.

Application:

Mainly used to measure motor speed, torque, output power, voltage, current, input power, frequency, and efficiency. Appliance Performance Test Lab

Main testing items:

In addition to all enterprise testing items, following functions are included:

1 DC resistance test under cold and thermal status.
2 No-load test: Acquire no-load characteristics curves through test, calculate the no-load current, no-load power and iron loss and mechanical loss.
3 Locked-rotor test: Acquire the locked-rotor characteristics curve through test, calculate locked-rotor torque and current.
4 Load test: This test is to acquire the load characteristics curve and calculate the motor parameters after modification. Appliance Performance Test Lab
5 Temperature rise test: Use resistance thermometry method to calculate the motor temperature rise. During test, motor winding temperature, core temperature and others are monitored by temperature detection apparatus.
6 T-N curve drawing: Draw T-N curve of induction motor in a real time and automatically test the maximum torque and minimum torque as well as the rotation speed of single-phase induction motor upon disconnection of centrifugal switch.

IEC 60034 Motor Performance Test Lab With Manual And Automatic TestingIEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
