IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
Specifications
Brand Name :
HongCe
Model Number :
HC9932A
Certification :
Calibration certificate(cost additional)
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30 set per month
Delivery Time :
30 days
Packaging Details :
carton box
Name :
Crush Test Apparatus for Handlamps
Warranty :
1 year
Material :
Stainless Steel
Test weight :
100N
Test sample :
Handlamps
Application :
Crush test
Steel jaws width :
15mm
Standard :
IEC 60598-2-8
Description

IEC 60598-2-8 Light Testing Equipment - Crush Test Apparatus for Handlamps 100N Force​​

Product information:

This test device is designed and manufactured according to the standard requirements of IEC 60598-2-8 clause 8.16.1 for handlamps having a handle or shell of flexible material, such as rubber or polychloroprene, compliance shall be checked by the following test.

The parts of the handlamp which are gripped in normal use are subjected to a pressure test in an apparatus similar to that shown in Figure 3, the test being made in a heating cabinet maintained at a temperature of 100 °C ± 2 °C. Light Testing Equipment

The sample is clamped between steel jaws, having a cylindrical face of 25 mm radius, a width of 15 mm and a length of 50 mm. The corners are rounded with a radius of 2,5 mm. Light Testing Equipment

The sample is clamped in such a way that the jaws press against it in the area where it is gripped in normal use, the centre line of the jaws coinciding as nearly as possible with the centre of this area.

The force applied through the jaws is 100 N.

After 1 h, the jaws are removed and the sample shall show no damage. Light Testing Equipment

Technical parameters:

Steel jaws width 15mm
cylindrical face radius 25mm
Steel jaws rounded corners radius 2.5 mm
The force applied through the jaws 100 N
Standard IEC 60598-2-8 clause 8.16.1

IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force

IEC 60598-2-8 Light Testing Equipment Crush Test Apparatus For Handlamps 100N Force
