Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
Specifications
Brand Name :
Molex
Model Number :
0039012041
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
500PCS
Payment Terms :
T/T, Western Union
Supply Ability :
4000PCS/WEEK
Delivery Time :
2-3DAYS
Packaging Details :
4000PCS/BOX
Price :
Negotiation
Product :
Wire Housings
Type :
Plug Housing
Number of positions :
4 Position
Pitch :
4.2MM
Rows :
2 Row
Installation style :
Panel
Termination type :
Crimp
Package :
Bulk
Housing material :
Nylon
Flammability rating :
UL 94 V-2
Line spacing :
4.2MM
Shell color :
Natural
Description

Documents

3D Model Application Specification AS-5557-001-001 (PDF) Drawing (PDF) Packaging Specification PK-5559-001-001 (PDF) Product Specification PS-45750-001-001 (PDF) RoHS Certificate of Compliance (PDF) Product Specification PS-5556-001-001 (PDF) Agency Certification CSA LR19980 UL E29179 General Product Family Crimp Housings Series 5559 3D Viewer Yes Application Power, Wire-to-Board, Wire-to-Wire Comments Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 series terminals crimped to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current derating information. Comments Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 series terminals crimped to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current derating information. Overview Mini-Fit Jr. Power Connectors Product Name Mini-Fit Jr. UPC 800753584303 Physical Breakaway No Circuits (maximum) 4 Color - Resin Natural Flammability 94V-2 Gender Plug Glow-Wire Capable No Material - Resin Nylon Net Weight 1.744/g Number of Rows 2 Packaging Type Bag Panel Mount Yes Pitch - Mating Interface 4.20mm Pitch - Termination Interface 4.20mm Polarized to Mating Part Yes Stackable No Temperature Range - Operating -40° to +105°C Electrical Current - Maximum per Contact 13.0A Solder Process Data Lead-freeProcess Capability N/A

Crimp Termination TE Relay Molex 0039012041 Header Wire Shell 4 CKT Plug Housing
