LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
Specifications
Brand Name :
Texas Instruments
Model Number :
LM339ADR
Certification :
ROHS
Place of Origin :
Mexico
MOQ :
10PCS
Price :
NEGOTIABLE
Payment Terms :
T/T, Western Union
Supply Ability :
12500PCS/WEEK
Delivery Time :
2-3DAYS
Packaging Details :
2500PC/REEL
Product Category :
Analog Comparators
Number of Channels :
4 Channel
Output Type :
Rail-to-Rail
Response Time :
300 ns
Comparator Type :
Differentia
Supply Voltage - Min :
2 V
Supply Voltage - Max :
30 V
Operating Supply Current :
500 uA
Output Current per Channel :
6 mA
Vos - Input Offset Voltage :
2 mV
Ib - Input Bias Current :
50 nA
Minimum Operating Temperature :
0 C
Maximum Operating Temperature :
+ 70 C
Features :
Standard comparator
Height :
1.58 mm
Length :
8.65 mm
Product :
Analog Comparators
Supply Type :
Single, Dual
Technology :
Bipolar
Type :
Differential Comparator
Width :
3.91 mm
Shutdown :
No Shutdown
Dual Supply Voltage :
+/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
Ios - Input Offset Current :
50 nA
Maximum Dual Supply Voltage :
+/- 15 V
Minimum Dual Supply Voltage :
1 V
Operating Supply Voltage :
2 V to 30 V
Product Type :
Analog Comparator
Voltage Gain dB :
106.02 dB
Factory Pack Quantit :
2500
Description

LM339ADR Texas Instruments Analog Comparators 100% Original​ Analog Comparators Quad Diff A Grade

1.Features
1• Wide Supply Ranges
– Single Supply: 2 V to 36 V
(Tested to 30 V for Non-V Devices and
32 V for V-Suffix Devices)
– Dual Supplies: ±1 V to ±18 V
(Tested to ±15 V for Non-V Devices and
±16 V for V-Suffix Devices)
• Low Supply-Current Drain Independent of
Supply Voltage: 0.8 mA (Typical)
• Low Input Bias Current: 25 nA (Typical)
• Low Input Offset Current: 3 nA (Typical) (LM139)
• Low Input Offset Voltage: 2 mV (Typical)
• Common-Mode Input Voltage Range
Includes Ground
• Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage: ±36 V
• Low Output Saturation Voltage
• Output Compatible With TTL, MOS, and CMOS
• On Products Compliant to MIL-PRF-38535,
All Parameters Are Tested Unless Otherwise
Noted. On All Other Products, Production
Processing Does Not Necessarily Include Testing
of All Parameters

2.Applications
• Industrial
• Automotive
– Infotainment and Clusters
– Body Control Modules
• Power Supervision
• Oscillators
• Peak Detectors
• Logic Voltage Translation

3.Description
The LMx39x and the LM2901x devices consist of four
independent voltage comparators that are designed
to operate from a single power supply over a wide
range of voltages. Operation from dual supplies also
is possible, as long as the difference between the two
supplies is 2 V to 36 V, and VCC is at least 1.5 V
more positive than the input common-mode voltage.
Current drain is independent of the supply voltage.
The outputs can be connected to other open-collector
outputs to achieve wired-AND relationships.
The LM139 and LM139A devices are characterized
for operation over the full military temperature range
of –55°C to +125°C. The LM239 and LM239A
devices are characterized for operation from –25°C to
+85°C. The LM339 and LM339A devices are
characterized for operation from 0°C to 70°C. The
LM2901, LM2901AV, and LM2901V devices are
characterized for operation from –40°C to +125°C.

4.Device Information(1)

LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original

5.Pin Configuration and Functions

LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original
