LVDC MIPI CCD CMOS Sensor High Sensitivity F5.6 1/30 Second Storage Time 2350mV
LVDC MIPI CCD CMOS Sensor High Sensitivity F5.6 1/30 Second Storage Time 2350mV
LVDC MIPI CCD CMOS Sensor High Sensitivity F5.6 1/30 Second Storage Time 2350mV
LVDC MIPI CCD CMOS Sensor High Sensitivity F5.6 1/30 Second Storage Time 2350mV
Specifications
Brand Name :
SONY
Model Number :
IMX225LQR-C
Certification :
Rohs
Place of Origin :
THAILAND
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
5600PCS/MONTH
Delivery Time :
3-5DAYS
Packaging Details :
560PCS/BOX
Type :
Area Sensors
Sensor type :
CMOS
Shutter type :
Rolling shutter
Pins / Balls :
140
Pixel size x [µm :
2
Aspect Ratio :
3:2
Pixel size y [µm :
2
Bit Depth :
10,12
Interface :
MULTI
Package :
LGA
Description

IMX225LQR-C LVDC CMOS MIPI Sensitivity F5.6 standard value 1 / 30 second storage time 2350mV green pixel

Sony IMX225MQV CMOS image sensor for automotive cameras, which boasts the world's highest sensitivity levels*1 of any image sensor of its kind. This sensor is capable of capturing high-resolution color images even in light conditions as low as 0.005 lux, a level equivalent to that of a moonless night and one that is far below illumination levels under a star-filled night sky.

Manufacturer: Sony
Type: Area Sensors
Sensor type: CMOS
Shutter type: Rolling shutter
Pins / Balls: 140
Pixel size x [µm]: 3.75
Aspect Ratio: 3 : 2
Pixel size y [µm]: 3.75
Bit Depth: 10, 12
Protective Film: yes
Chromatics: color
Resolution [MP]: 1.27
Sensor size [inch/mm]: 1/3 inch
Frame rate [fps]: 60
Sensor technology: Exmor
Further specification: LVDC/CMOS/MIPI, Sensitivity (F5.6 standard value, 1/30 second storage time) - 2350mV (green pixel), without WDR function
Horizontal Resolution: 1305
Interface: MULTI
Vertical Resolution: 977
Package:

LGA
