1 Channel Video Optical Transceiver 5VDC/2A Input Power CE Certificated
1 Channel Video Optical Transceiver 5VDC/2A Input Power CE Certificated
Specifications
Brand Name :
3onedata
Model Number :
SWV61100
Certification :
CE, FCC, RoHS
Place of Origin :
Shenzhen, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 sets per month
Packaging Details :
Carton
Delivery Time :
7 Working Days
Video Ports :
1
Fiber Ports :
1
Data Ports :
1
Input Power :
5VDC/2A
Operating Temperature :
-15~65℃
Warranty :
3 years
Description

1-channel TVI/CVI/AHD video to fiber converter

Introduction

Our 1-Ch TVI/CVI/AHD to Fiber Converters is universal type supporting High Definition Analog video format HD-TVI/HD-CVI/AHD, can simultaneously transmit 1 channels video and 1-ch RS485 over one core multimode or single-mode optical fiber. It also supports the regular analog video format such as PAL/NTSC/SECAM; it is a kind of universal fiber transmission solution/product for CCTV analog video/data signals. Devices are available for either standalone or rack-mount installation, which is suitable for different working environment. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status.

Specification

Optics

Wavelength: WDM:1310nm/1550nm

Output Power: -8~3dBm

Optic fiber: 50/125u multimode, 62.5/125u multimode, 9/125u single mode

Rx sensitivity: -23dBm

Optical connector: FC, ST, SC (optional)

Distance: 0~550M (MM)/0~80KM (SM) (Default distance is 20Km)

Video

Number of Channels: 1

Input/output impedance: 75 Ohm (unbalance)

Standard video input/output voltage: 1.0Vp-p

Video Bandwidth: 50MHz

Sampling Bandwidth: 8bit

Sampling Frequency: 100MHz

Signal to noise ratio: >67dB

Rise and Fall time: <0.8ns

Optical Signal Intrinsic Jitter: <0.2 UI

Differential Gain: < ±1.5%

Differential Phase: < ±1°

Connector: BNC

720P Support video pixel:

1280(H)x720(V)@30Hz/1MPX

1280(H)x960(V)@30Hz/1.3MPX

1080P Supporting video pixel:

1280(H)x720(V)@30Hz/1MPX

1280(H)x720(V)@50Hz/1MPX

1280(H)x960(V)@30Hz/1.3MPX

1920(H)x1080(V)@30Hz/2MPX

Data

Protocol: Default: RS485 (RS232/RS422 Optional)

Number of channels: 1

Connector: 5pins Terminal Blocks

Data Rate: 0-200Kbps

Directions: Default: Simplex from Rx to Tx (BIDI duplex optional)

Mechanical

Structure

&

Environment

Power: DC5V 2A

Power Consumption: ≤6W

Working Temperature: -15℃ ~65℃

Storage Temperature: -40℃ ~85℃

Relative Humidity: 5%~95% ( no condensation)

MTBF: ≥ 100000Hours

Application

1 Channel Video Optical Transceiver 5VDC/2A Input Power CE Certificated

Ordering Information

Model Number

Product Configuration

Remark

Fiber Mode

Wavelengths

Transmission Distance

SWV61100

1Ch Forward AHD Video 1080P

FC/SC/ST

Single-mode

1310 nm

20Km

SWV61101

1Ch Forward AHD Video 1080P +1Ch Reverse Data

FC/SC/ST

Single-mode

WDM

1310/1550 nm

20Km

Options

1

standard definition/720P/1080P

2

1A↓ 1 reverse audio

3

1A↑↓ 1 bi-directional audio

4

1D↑ 1 positive data(RS-485/422/232)

5

1D↓1 reverse data(RS-485/422/232)

6

I/O 1 I/O

7

FXS/FXO 1 FXS/FXO

8

Ethernet 1 Ethernet

9

2U 16" rack, redundant power

10

4U 18" rack, redundant power

Packing information

Dimensions of products (Pcs per Tx or Rx)

Module name

Configuration

Long (mm)

Wide(mm)

High(mm)

Volume(mm³)

SWV61100

1-Ch video 1080P

108

102

27

297432

SWV61101

1-Ch video 1080P + 1-Ch RS485 data

108

102

27

297432

Shipping weight (pair /Tx+Rx & power adaptors & packages)

Module name

Configuration

weight (kg)

Package type

SWV61100

1-Ch video 1080P

0.95

Carton box

SWV61101

1-Ch video 1080P + 1-Ch RS485 data

1.0

Carton box

Remark

  • Optical transmission distance is limited to optical loss of the fiber and any additional loss introduced by connectors, splices and patch panels.
  • Maximum transmission distance is also limited by fiber bandwidth.
  • Power adapter for stand-alone units is manufactured by third party .Power adapter included US, European, UK or Australian power plug.
  • Please feel free to contact factory for any special requirement and customization.
