7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
Specifications
Brand Name :
BMP -Stainless Wire Rope Mesh
Model Number :
ZOO WIRE MESH
Certification :
ISO
Place of Origin :
China
MOQ :
50sqm
Price :
9.88$/m2
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
20000sqm per week
Delivery Time :
3-5 days
Packaging Details :
Plastic Bag
Material :
Stainless Steel Wire,316,Steel,304L,stainless steel 304
Type :
Weave Wire Mesh,Rope Mesh,Ferruled mesh,stainless steel decorative wire mesh,Self-Locking
Weave style :
Plain Weave,handmade,Twill,dutch,stainless steel rope mesh
Technique :
Woven,Welded Mesh,Weave
Application :
Protecting Mesh,Woven Wire Mesh,Filters,Zoo,airport
Feature :
Corrosion Resistance,rustless,ect,Light weight,high-strength
Product name :
SS 304 decorative wire mesh,smoking pipe filters,X-tend Kontted Type Stainless Steel Inox Cable Wire Rope Mesh,sus304 stainless steel wire mesh,Flexible stainless steel wire rope cable rope ferrule mesh
Hole shape :
Square Hole,Diamond,Rectangular,rhombus,round hole
Wire diameter :
Requirement,1.2-5mm,1x7 7x7 7x19 or customized
Usage :
Protecting mesh,decorative wire mesh,Filter/acid resistance/high magnetic
Color :
Silver,blue or as your request,yellow,black,requirement
Length :
Customsized
Width :
1.0m-48m or customerized
Surface treatment :
stianless steel
Sample :
available
Size :
customized
Mesh aperture :
customized
Aperture :
customized
Warranty :
10 years
Description
7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh Enclosure Netting

The Zoo Wire Mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm. Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.
Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.
Finished diamond mesh style when it is stretched at 60 degree angle ;

1. Material of Stainless Steel Zoo Wire Mesh : Stainless steel 304,304L,316,306L etc.

SS304 (%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316 (%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L (%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0


Recommended Monkey Enclosure Zoo Wire Mesh:

Material Cable Diameter Hole Size Normal Break
SS304/316/316L 3/32" (2.4MM) 2.5" x 2.5" 920 LBS
SS304/316/316L 3/32" (2.4MM) 2" x 2" 920 LBS
SS304/316/316L 5/64" (2.0MM) 2.5" x 2.5" 676 LBS
SS304/316/316L 5/64" (2.0MM) 2" x 2" 676 LBS
SS304/316/316L 1/8" (3.2MM) 2" x 2" 1600 LBS
SS304/316/316L 1/8" (3.2MM) 3" x 3" 1600 LBS


Stainless steel zoo wire is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.

7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh7x7 Stainless Steel Tiger Metal Zoo Wire Rope Mesh
