Specifications
Brand Name :
LNF-Crowd Control Barriers
Model Number :
1090mm Height*2500mm Width Crowd Control Barriers
Certification :
ISO
Place of Origin :
American ,Australia ,Canadan
MOQ :
500 liner meter
Price :
18.88$ per set
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 steel pipes
Color :
Any Ral color
Type :
Weld Steel
Warranty :
3-25 years depand on treatment
Pipes :
OD 25 mm ,32mm ,38mm
Customized :
Available
Treatment :
Hot Dipped Galvanized Or Powder Painted
Market :
World Wide
Description

"v" foot welded model crowd control barrier 1090mm x 2500mm upright OD 16mm outer 35mm

Overall Length: 2300mm(2250when interlocked) or as stipulated
Overall Height: 1100mm or as stipulated
Weight: 12kgs ± 0.5kgs
Material: Steel tube.

Main Frame:
Outside perimeter (mainframe) is made of 38mm diameter galvanized steel tubing, minimum 1.4mm thickness(after coating). The outer frame is a single length of tubing without welds or deformation. The pipe is bent at right angles with a minimum of smooth deformation. Horizontal and vertical bars are at right angles to the overall frame.

Grill: 15 equally-spaced bars inside vertical members, made of 13mm out diameter galvanized steel tubing, minimum 1.0mm(after coating),15 interior bars are 119mm apart, O.D. to O.D.

Locking: Male-Female interlocking ends. Units join and unlock at one position (30 degrees). The male interlocking device is a minimum 10mm diameter rod welded through mainframe at both ends. Male/Female connections have enough clearance to allow for uneven ground, a minimum of 13mm on top and bottom when connected.

Feet: "v" foot welded on the frame

Finish: All tubes hot dip galvanized tube welded then spraying zinc paint on welded points.

Another finish:
powder-coated black, powder-coated orange or another colour.

Warranty: above 3-year warranty against hot dip galvanised tube material and spray zinc paint on welding points, above 10 years for powder coating or vinyl coated finishing(anti-rusting warranty).
Hot dip galvanized
Packing
Packing
