4-600mm Weld Overlay Services Inconel 625 Cladding Seamless Tube Pipe Bar
4-600mm Weld Overlay Services Inconel 625 Cladding Seamless Tube Pipe Bar
4-600mm Weld Overlay Services Inconel 625 Cladding Seamless Tube Pipe Bar
4-600mm Weld Overlay Services Inconel 625 Cladding Seamless Tube Pipe Bar
Specifications
Brand Name :
Cheonny
Model Number :
Inconel 600 Stainless Steel Round Rod
Certification :
ISO9001 ,ASME , EN, JIS, AiSi, GB, DIN, API
Place of Origin :
China
MOQ :
5 tons
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 Tons/Month
Delivery Time :
30 working days
Packaging Details :
Customized
Diameter :
4-600mm (3/8"-25")
Application :
Structural Steel Bar
Special Use :
Cold Heading Steel
Surface :
BA,2B,NO.1,NO.4,4K,HL,8K
Technique :
Forging and cold drawing
Processing Service :
Bending, Welding, Decoiling, Cutting, Punching
Description

Inconel 625 Cladding Seamless Tube Pipe Bar On-site Weld Overlay Services

High temperature alloy has the high temperature hot corrosion and high temperature abrasion resistance,the metal material can work long-term which above 600 ℃ with under certain stress conditions.

Inconel 625

Features:Inconel 625 has excellent strength at temperatures up to 816℃. At higher temperatures, its strength is generally lower than that of other solid solution strengthened alloys. Inconel 625 has good oxidation resistance at temperatures up to 980℃ and shows good resistance to aqueous corrosion, but is relatively moderate compared to other more capable corrosion resistant alloys.

Applications:Chemical process industry and sea water application. Inconel 625 is used in short term applications at temperatures up to 816℃. For long term service, it is best restricted to a maximum of 593℃, because long term exposure above 593℃ will result in significant embrittlemen

Chemical Composition

Cr Ni Mo Co Nb Al Ti C
20.00-30.00 Remainder 8.0-10.0 1.0 max 3.15-4.15 0.40 max 0.40 max 0.10 max
Fe Mn Si P S
5.0 max 0.50 max 0.50 max 0.015 max 0.015 max

Density and Melting point

Density Melting point
8.44g/cm³ 1290-1350°C

Mechanical Properties

Finish Condition Tensile strength Rm N/mm² Yield strength R P 0. 2N/mm² Elongation (%) Min HB
Solution treatment 760 345 30 ≤220

4-600mm Weld Overlay Services Inconel 625 Cladding Seamless Tube Pipe Bar

Material Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar,
Grade Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc
Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC
Incoloy: Incoloy 800/800H/800HT/825/925/926;etc
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc
Monel: Monel 400/K500/R405,etc
Nitronic: Nitronic 40/50/60;etc
Nimonic: Nimonic 75/80A/90/A263 ;etc
Specification Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product
Characteristics		 1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Inspection ISO,SGS,BV and so on.
Packaging All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.
