256x128mm Aluminum Die Cast Outdoor Digital Advertising Display Screens
256x128mm Aluminum Die Cast Outdoor Digital Advertising Display Screens
256x128mm Aluminum Die Cast Outdoor Digital Advertising Display Screens
256x128mm Aluminum Die Cast Outdoor Digital Advertising Display Screens
Specifications
Brand Name :
JuCaiYuan
Model Number :
Outdoor P8
Certification :
UL/CE/ROHS/FCC
Place of Origin :
Shenzhen,China
MOQ :
3 Square meters
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
60000Sqm per month
Delivery Time :
5-10 days
Packaging Details :
Strong Carton Box, Wood Case, Flight Case, Road Case
Pixel Pitch(mm) :
8mm
BrightnessDetail :
≥6500cd/sq
Application :
Outdoor,subway Station,highway Station Advertising,train Station
Cabinet size :
1024mm*1024mm
Input Voltage :
AC110V - AC240V
Display :
Video
High Light :
led video wall module, led module screen
Tube chip color :
1R1G1B
Description

256mm X 128mm Outdoor Advertising LED Display With Aluminum Die Cast

Product advantages:


1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.

2) Quality advantage: From material to finished product, from design to produce, we control all steps

3) Service advantage: Better service at same situation, better cooperation at same service

Specification

Item Parameter Item Parameter
Pixel Pitch 8mm LED Encapsulation

SMD3535/

1R1G1B
LED Chips Epistar Module resolution 32dots*16dots
Module size(mm*mm) 256mm*128mm Pixel density 15625dots/m²
Weight 0.56KG Drive chip 2026
Drive Method: 1/4scanning Brand of power supply CL 5V~40A
Gray Scale Recommended 256 level The best viewing angle

Horizontal:140

Vertical:90
Max Power Consumption 1000W/ m² Control Mode

Video frequency

synchronization
Optimal Viewing Distance ≥8m Brightness ≥7000cd/m²
Blind Spot Rate <0.0001 Brightness Control 0-255 Grade
Contrast 100 levels adjustable

Earth Leakage

Current

 <2mA
MTBF >5000Hours Lifespan >100000Hours
Power Supply Mode

AC220V/50HZ or

AC110V/60HZ

 Protection Level IP65
Humidity 0%~90% Operating System

Windows98/me/

2000/NT/XP
Operating temperture Operation:-30°C~+60°C

Trade Terms:


1) Payment: T/T ,ususally 40% prepayment before production, 60% balance to be paid before delivering,it also change according to total quantity
2) Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days
3) Sample can be deliveried within 3days
4) Shipping port: Shenzhen, Mainland China
5) Discounts are offered based on order quantities
6) MOQ:1 sqm/1pcs
