4200nit 1200Hz ISO Multicolor Scrolling LED Signs
4200nit 1200Hz ISO Multicolor Scrolling LED Signs
Specifications
Brand Name :
jucaiyuan
Model Number :
JCD-44
Certification :
CE,ROHS
Place of Origin :
shenzhen, China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Display Color :
1R1G1B
Display Function :
Video , Text, Messages, Pictures
Working Voltage :
AC220V±10%50Hz Or AC110±10%60Hz
Control System :
AV,S-Video,VGA,CVBS,HDMI
LED Display Useage :
Front Side: IP65, Backside: IP54
Certificate :
UL CE, RoHS, FCC, ISO Etc.
Description

Multifunction Colorful SCrolling LED Signs P10 for Commercial Advertising

1. The strong and precise die-cast aluminum frame strengthens the fastness and impact resistance.
2. Simple installation and dismantlement .In case of taking out of the whole.,the users can realize it just by four unlocking and one pushing,without any move on its adjacent panel modules.
3. The unique auto-locking design makes the setting and maintenance more convenient and flexible.
Application occasion:
Indoor and outdoor stage setting in rental business: TV entertainment, outdoor show event and rental application

Product Description:

1. Housing color is Black
2. Housing material is Aluminium
3. Font size of text message is adjustable
4. Display function is text message and graphics
5. Flash memory can store several different messages
6. Input voltage is AC 110V-230V; DC 9V-36V if vehicle application
7. Signal connection cable interface is USB(default), RS232, RS485 or TCP/IP network
8. Multi-actions for displaying, including snow, spray, twinkle, rotate, scroll, star burst, wipe and etc
9. Text message can be scrolling and programmed by computer via USB interface
10. Product can support all the languages in the world, English, Spanish, Russsian, French, Hebrew, etc

Technology Specifications

Pixel Pitch 20 mm
Pixel Matrix 32X32 dot
LED Quantity/Module 2500 dot
Pixel Configuration SMD 3-IN-1
Brightness 4200nit
Data refresh rate 1200 Hz
Gray scale 12 bit
Brightness adjustment 256 level
Color 68.7 Billion
Unit Size 960X960X100mm/panel
Unit area 0.41sqm/panel
Weight 8 kg/panel
Power Consumption 200w/panel
Viewing angle 160 /140
Shortest viewing distance 20m
Transparency 40%
Out-of-control point <0.0002
Tenure life of lamp-hour(50% Brightness) >50000 hour
Work Temperature -10C~+40C
Relative Humidity 10%~90% RH
Protection Level IP 54
Work Voltage AC110-240V/50-60Hz
Drive Mode Static constant current
Operative System Windows (2000/XP/Vista)
Control System AV,S-Video,VGA,CVBS,HDMI,DVI
Control Distance HSYV;<100m

Package including:
1. LED sign 1 pc
2. Power wire cable 1 pc
3. Signal communication cable 1 pc
4. Professional installation bracket 2 pcs
5. CD-ROM with control software and User manual 1 pc

4200nit 1200Hz ISO Multicolor Scrolling LED Signs

4200nit 1200Hz ISO Multicolor Scrolling LED Signs
