Hotel P2mm Super HD 640x1920mm LED Wall Poster
Hotel P2mm Super HD 640x1920mm LED Wall Poster
Specifications
Brand Name :
JuCaiYuan
Model Number :
P2
Certification :
CE ROHS FCC
Place of Origin :
Shenzhen,China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 ㎡/month
Delivery Time :
12-20 working days after deposit
Packaging Details :
Standard wooden case or flight case packing as customer's request
Name :
LED Poster Display
LED Poster Display :
SMD1515
Color :
1R1G1B
Usage :
indoor
Resolution/mm :
2mm
Application :
Hotels, Restaurants, Shopping Malls, Banks,
Brightness :
1200 Cd/m2
Life Span :
100000 Hours
Description

Indoor advertising player P2mm Super HD LED Poster Display 640*1920mm Hotel Restaurant

Product Description

LED Poster is a new intelligent terminal advertising player. It forms a complete multimedia system through terminal software control, network information transmission and multimedia terminal display, and it advertises through multimedia materials such as pictures, text, videos and so on.

As a medium for advertising, it can be used both in outdoor & indoor and also rich in form. It can be used as advertising player, emergency notification, instant information release, guide purchase information, supporting service information release, publicity plat form, brand demonstration.

LED Poster is suitable for convention and exhibition center, shopping center, conference, hall, wedding, performance, airport station, supermarket. restaurant, movie studio and other occasions.

Feature

1. Plug and play zero setting.
2. Support Iso&Android devices.
3. Easy to opeartion,control by special mobile APP LEDArt to connect to the screen WIFI.
It support shot and send.
4. Ultra-thin&Ultra light design,the weight is only 36kg/pcs and the thickness is 30mm.
5. Can support 10pcs unit together with no gap compared with the similar product.

Product specification

Item Technical parameter
Pixel Pitch 2mm
Module Resolution 160*80 dots
Module Size 320*160mm
Pixel configuration 1R1G1B
Module Chip Kinglight/Nationstar
Driving Method 1/32Scan
Physical Density 250,000 dots/m2
LED Encapsulation SMD1515
Module Port BUH75
Module Consumption ≤16W
Brightness 1200 cd/m2
Cabinet Dimension 640*1920mm
Cabinet External Dimensions 700*1980*100mm
Cabinet Resolution 320*960 dots
Quantities of module 2*12
Cabinet Flatness Tolerance of inter pixel ≤0.3mm
Cabinet Material Aluminume,Iron
Cabinet Weight 38KG
Option Distance 2--80M
Viewing Angle Horizontal 140° Vertical 120°
Max. Power consumption 675W/sqm
Driving Device ICN2153IC
Frame Frequency 60Hz
Screen Flatness Tolerance of cabinets ≤0.6mm
Refresh Frequency 1920Hz/3840Hz
Control Mode Wifi asynchronization
Working Environment

Temperature -10℃~60℃

Humidity 10%~70%
Display Working Voltage AC110V/220V , 50Hz/60Hz
Colour temperature 8500K-11500K
Communication distance

Network cable: 100m, Multi-model: 500m,

Single-model fiber: 20km
Gray scale ≥16.7M
MTBF >10,000 hours
Support video source HDMI, CVBS, SDI , DVI etc
