Specifications
Brand Name :
JuCaiYuan
Model Number :
Outdoor P2.5
Certification :
UL/CE/ROHS/FCC
Place of Origin :
Shenzhen,China
MOQ :
3 Square meters
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
60000Sqm per month
Delivery Time :
5-10 days
Packaging Details :
Strong Carton Box, Wood Case, Flight Case, Road Case
Product Name :
P2.5 Outdoor Full-color Display Screen
Pixel Pitch :
2.5 Mm
Application :
Outdoor,subway Station,highway Station Advertising,train Station
color :
Full Color,RGB LED Display
Refresh Rate :
1000-3000 Hz Adjustable
BrightnessDetail :
≥6500cd/sq
Description

Large Outdoor Full Color LED Display For Bus Station Delicate Appearance P2.5

Product Features:

1. SMD led encapsulation confirm wide view distance and good uniformity

2. High brightness,good waterproof IP65,anti-corrosion,anti-rust,long life span>100000hours

3.High pixel density, high resolution and high definition,perfect display vision

4. Lower power consumption,good heat dissipation,low noise created.

5. Cabinet with locks,connectors,easy and quick to assemble without tools in short time

6. Widely used for commercial display,advertising, stage background,mobile display. traffic display,sports led display etc.

Concept of LED Display


1.High contrast
LED professional lamp bead USES high quality 2121 black lamp, raise luminescence brightness, reduce screen black time brightness at the same time.
Unique black mask processing technology, the screen contrast is greatly improved.
2.High gray level
The display of the screen is almost perfect with low brightness, and the appearance of the screen is higher than the traditional display.
That can show more image details, no information loss.
3.High refresh rate
The screen intake five black screen picture stability without ripples, dealing with the dynamic display screen, the image edge is clear, the screen has good dynamic performance, the image information accurately real reduction, make the video screen clear fluid, bring good visual enjoyment.
4.Wall installation to streamline space
Pasted wall, Mosaic, landing multiple installation methods, simple and beautiful, the maintenance of post-maintenance is more simple and convenient.

Specifications :

Technical Specification
Pixel Pitch 2.5mm
Pixel Dendity 160000pixels/sqm/㎡
Pixel Configuration 1R1G1B
Module Size 320mmx160mm
Body size R=250mm/R=500mm
Pixels/Module 104x52=2048
Driving Method 1/13scan
Optimal Viewing Distance >3m
Operating Temperature -20°C ~ +50°C
Optimal Viewing angle Horizontal 140 / vertical 140
Maximum Power Consumption 1500w/sqm
Average Power Consumption 500w/sqm
Brightness 5000cd/㎡
Refresh Rate 1000-3000 Hz adjustable
Power Supply 220V/50HZ/110V/60HZ
Weight 15 kg per square
Life Span (50% brightness) ≥100,000hours
Control Mode synchronization with PC/Asynchronous
System Operating Platforms WIindows/Tablet/Laptop/Mobile PhonesWIindows
Input Signal Format VGA, DVI, RGBHV, S-Video, TVVGA, DVI, RGBHV,S-Video, TV
Maintenance Front/Back Service

6500cd/sq P2.5 Outdoor Round LED Display 500w/sqm

FAQ:

What is the life time for a LED screen?

The life time for the LED screen is basically over 100,000 hours, but it depends how the client is taking care of his LED screen and how it is used. When a LED Screens´ life time gets to 100,000 hours, it means that the brightness of the LED lamps of the LED screen is about 50% off as compared to the original brightness depending on several factors that will enlarge a LED screen´s life time or reach 100,000 hours.

What is the led chip packing?

546 oval lamp/346 oval lamp/SMD 3528/8X8 Array module

How to protect power supply?

Electrical peaks can put more force on the electrical components which will decrease life time .

it is wise to install a protection (voltage stabilizer) that can control the peaks.

How to main the led screen?

The soldering of the LED chips can dry out and break which require changing often components such as LED modules and receiving card .

What is the return policy?

If the module died exceed 1%,we can resend you the new one.
