Specifications
Brand Name :
JuCaiYuan
Model Number :
P6 P8 P10
Certification :
CE/ROHS/FCC
Place of Origin :
Shenzhen,China
MOQ :
1 Square meter
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000sqm per month
Delivery Time :
3-25 working days after finished the payment
Packaging Details :
Strong Carton Box, Standard Wood Case, Flight Case etc
product :
Transparent P3.91 mm LED Display
Brightness :
Over 5000nits
Warranty :
2 Years
Application :
Indoor
Technology :
Frontage-lighting
Screen Dimension :
Customized
Material :
Acrylic Frame Rental Led Wall
High Light :
transparent led curtain display, glass wall led display
Description
Overview
Quick Details
Application:
OUTDOOR
Color:
FULL COLOR
Panel Size:
Customized
Pixel Pitch:
6.67mm, 8mm, 10mm
Place of Origin:
Shenzhen, China
Model Number:
P10 P6 P8
Brand Name:
Jucaiyuan
Function:
SDK
Type:
LED
Item:
Advertising Display Panel Board Led Screen For Football Stadium
Pixel Configuration:
3in1 SMD3535
Pixel Pitch (mm):
10
Cabinet size (mm):
960*960
Cabinet material:
Magnesium Alloy
Keyword:
outdoor led screen price / led screen price
Refresh Rate (Hz):
1920
Brightness (nit):
6000
Viewing Angle(°):
H:120; V:120
Operating Temperature/Humidity (°C):
-20°C~50°C/10~90%RH
Supply Ability
Supply Ability
2000 Square Meter/Square Meters per Month
Packaging & Delivery
Packaging Details
P6 P8 P10 Smd Outdoor Large Perimeter Advertising Display Panel Board Led Screen For Football Stadium packaged by wooden case.
Port
shenzhen port
Lead Time:
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 15 To be negotiated
view more >>Recommended by seller

Application
Product Description
Technical Parameter
P6
P8
P10
Pixel Configuration
SMD2727
SMD3535
SMD3535
Pixel Pitch(mm)
6.67
8
10
Module Resolution(dots)
48x24
40x20
32x16
Panel Resolution(dots)
144x144
120x120
96x96
Pixel Density(dots /m²)
22477
15625
10000
Module Size(L x W x H)/(mm)
320x160
320x160
320x160
Panel Size(L x W x H)/( mm)
960x960
960x960
960x960
Panel Material
Die-casting magnesium
Die-casting magnesium
Die-casting magnesium
Panel Weight(kg/panel)
28
28
28
Refresh Rate(Hz)
≥1920
≥1920
≥1920
Driver Method
1/6
1/5
1/2
Brightness(nit)
≥5500
≥5500
≥6000
Viewing Angle(H/V°)
140/100
140/140
140/140
AC Power Input(V)
AC220±10%
AC220±10%
AC220±10%
Max. AC Power Input(W/m²)
1000
1000
1000
Avg. AC Power Input(W/m²)
300
300
300
Storage Temperature(℃)
-40~60
-40~60
-40~60
Working Temperature(℃)
-20~50
-20~50
-20~50
IP Rating
IP65
IP65
IP65
Installation Types
Rear Installation
Rear Installation
Rear Installation
Maintenance Types
Rear Maintenance
Rear Maintenance
Rear Maintenance
Packing&Shipping
