Specifications
Brand Name :
EliteLED, OEM
Model Number :
Outdoor p2.97
Certification :
CE
Place of Origin :
China
MOQ :
1sqm
Price :
Negotiable
Supply Ability :
3000sqm/month
Delivery Time :
18 days
Packaging Details :
Flight case
Pixels :
2.97mm, 3.91mm,etc.
Color :
Full color
Product name :
P2.9 led video wall
Brightness :
4800 cd/sqm
Panel size :
500x1000mm
Refresh rate :
3840Hz
LED chip :
Nationstar, Kinglight
Usage :
Outdoor
Description

Description of Rental LED Screen

Outdoor Waterproof Led Screen pixel include 4mm, 5mm, 6.67mm, 8mm, 10mm, 16mm, within these pixels, 4mm, 5mm, 6.67mm are the most hot-selling and highest cost-effective series. You can use it on car for advertising or fixed in some place as billboard or on building.

Specification of Rental LED Screen

BOF-B-4 BOF-B-5 BOF-6
Physical Pitch 4mm 5mm 6.67mm
Pixel Configuration SMD1818 SMD2727 SMD2727
Pixel Density 62,500 pixels/Sqm 40,000 pixels/Sqm 22,376 pixels/Sqm
Module Dimensions(W x H) (mm) 320 x 160 320 x 160 320 x 160
Panel Dimensions (mm) 960 x 960 x 150 960 x 960 x 150 960 x 960 x 150
NO. of Modules Per Panel (W x H) 3 x 6 3 x 6 3 x 6
Physical Resolution of Module (W x H) 80 x 40 64 x 32 48 x 24
Physical Resolution of Panel (W x H) 240 x 240 192 x 192 144 x 144
Panel Material Steal / Aluminum Steal / Aluminum Steal / Aluminum
Weight (kg/Sqm) 65 / 45 65 / 45 45
Processing 16bit 16bit 16bit
Colours 281 trillion 281 trillion 281 trillion
Contrast Ratio 2,000 : 1 2,000 : 1 2,000 : 1
Average Power Consumption 360 W /Sqm 360 W /panel 360 W /panel
Max Power Consumption 900 W /Sqm 900 W /panel 900 W /panel
Brightness >6,500 nits >6,500 nits >6,500 nits
Refresh Rate >1,920 Hz >1,920 Hz >1,920 Hz
Vertical Viewing Angle 160° 160° 160°
Horizontal Viewing Angle 140° 140° 140°
Expected Lifetime 100,000 Hrs 100,000 Hrs 100,000 Hrs
Servicing Rear Rear Rear
IP Rating (Front/Rear) IP 65 IP 65 IP 65
Operating Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%
Storage Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%
Scan Method 1/8 Scan 1/8 Scan 1/8 Scan

Feature Of Indoor Rental LED Screen

  • High IP Rating IP65, good waterproof and dust resistance, suitable for every condition.
  • Wide viewing angle 160° for broader reach, seamless in all direction with same image quality output, suitable for large gatherings.
  • High brightness from 6,000nits to 9,000nits, visible from every direction even face to direct sunshine.
  • Good heat dissipation with fans and using meanwell power supply, long lifespan.
  • You can adjust the resolution by change modules directly, this can save your cost and labor.
  • 250x250mm module, compatible with various pitches such as PH2.6/PH2.9/PH3.9, high selectivity
  • High-precision and ultra-practical design, 500x500/1000mm cabinet, light and easy to assemble
  • Customized arc-side locks design, the angle can be adjusted to achieve arc, round and S-shaped splicing.
  • High-contrast outdoor pure black light, non-destructive refresh and grayscale. Achieve ultra-high contrast 8000:1, low brightness 1000~3000cd adjustable, protect the human eye, meet indoor and outdoor application scenarios
  • Configure PWM constant current drive IC to eliminate the "caterpillar" image, low brightness and no color cast, no color block, gray scale is too smooth and no jump, no first line dark phenomenon, refresh ≥ 3840HZ, complete guarantee 16bit gray scale, Real color reproduction, high quality display
  • The flat spray mask design ensures that the entire screen plane is free of any warping, and the high-quality black protective colloid is used to perfectly realize the full-angle display of the lamp bead.

Application Of Indoor Rental LED Screen

  • Business organizations

Supermarket, large-scale shopping malls, star -rated hotel, travel agencies.

  • Financial organizations

Bank, insurance companies, post offices, hospital, schools

  • Public place

Subway, airports, stations, parks, exhibition halls, stadiums, museums, commercial buildings, meeting room

  • Entertainments

High Brighness IP65 Outdoor Rental Led Screen Waterproof 4800Cd/Sqm

LED Advertising Display Advantages:
1, High quality SMD led panels, stable and high durability.
2, Without ghosting, clear and clean.
3, High fresh rate up to 2,000Hz, high contrast to 2,000:1, vivid color.

Our Services

1. 7 Years professional led display manufacturer,

2. Shot delivery time: 5-15days.
3. Factory price.

4. OEM and ODM service
5. We can design special product for you.

6. 30% deposit for producing,70% balance to be paid before shipment.

7. EXW, FOB, CIF C&F, FCA, DDU, colorful trade term.
