Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen
Specifications
Brand Name :
EliteLED
Model Number :
Outdoor p3.91, p4.81
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
1sqm
Price :
Negotiable
Supply Ability :
3000sqm/month
Delivery Time :
18 days
Packaging Details :
Wooden cases or flight cases
Application :
Outdoor Advertising
Pixel Pitch :
4.81mm
Brightness :
6000nits
Product name :
P4.81 Outdoor Led Panel
Cabinet size :
1000x1000mm
LED chip :
Nationstar
Control system :
Nova
Certificate :
CE ROHS
Warranty :
2 Years
Description

Front Access P3.91 P4.81 Outdoor Fixed Led Display Wall Mounted Aluminum Panel

Specifictions:

1. Front access, slim aluminum cabinet, easy and fast to install and maintenance.

2. 2.8V&3.8V energy saving design, no need air-conditioner, environmental and save cost.

3. Very simple steel structure, wall mounted installation, support seamless splicing at 90 degree corner.

4. Totally warterproof of front and back, certification:CE, FCC, IP65

5. Competitive price, you are welcome to contact us for a free project evaluation.


Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen

Model No. P10.41 P7.8 P6.25 P5.2 P4.8 P3.9
Pixel pitch 10.4mm 7.82mm 6.25mm 5.2mm 4.81mm 3.91mm
Pixel density
(dots/m2)		 9246 16352 25600 36982 43264 65536
LED encapsulation SMD2727 SMD2727 SMD2727 SMD2727 SMD1921 SMD1921
Scan rate 1/2 scan 1/4 scan 1/5 scan 1/6 scan 1/7 scan 1/8 scan
Module size 500 x 250 mm
Module Resolution 48 x 24 64 x 32 80 x 40 96 x 48 104 x 52 128 x 64
Cabinet size 1000 x 1000 x 73mm (Optional)
Cabinet Resolution 96 x 96 128 x 128 160 x 160 192 x 192 208 x 208 256 x 256
Weight per Cabinet 24.5 kg
Brightness ≥6500/
10000nits		 ≥6000/
10000nits		 ≥6000/
10000nits		 ≥5500/ ≥5000/ ≥5000/
Max.power consumption 500W 500W 500W 550W 800W 800W
Ave.power consumption 175W 175W 175W 185W 270W 270W
Energy Saving design 2.8V & 3.8V Low voltage 4.6V / 5V voltage
Protection Degree Front IP67/Rear IP65
Service Front & Rear Dual service
Power Supply AC120 /240V (50Hz) (optional)
Refresh Rate ≥ 1920Hz(3840Hz Optional)

Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen

About Us:

Shenzhen Eliteled Electronics Co. Limited is a full range manufacturer and LED display solutions provider and its ancillary systems worldwide since 2009, headquartered in Shenzhen with a 6, 000m² production state of the art facility to cover international demands. We provide a one-stop shopping in the design, production, and distributions of LED displays and solutions for our customers domestically and globally.

Our products include ranges of indoor, outdoor, fixed, rental and creative LED Solutions for various applications including sports, advertisement, concerts, shopping malls, stadiums, exhibitions or any other indoor and outdoor events that comes to your imagination.

Front Access 1000x1000mm P4.81 Outdoor Advertising Billboard Wall Mounted Led Screen

After-sale Service:

1. Warranty is for 2 years: During the warranty period, we will maintain and replace the defect components for free if there is any quality problem due to us. After 2 years, we will charge the material and freight cost.

2. Free Training: You can send your engineers to our factory for free of charge training, which includes the software, operation, installation, adjustment, basic repairing, etc.

3. Technical Support: All operation manuals, software, CAD drawings of the steel structure and instruction of installing the cabinets can be provided for free. Online technical support by remote control is also available. If needed, we can send engineers to your country to instruct and help the installation.

4. If you need, we can send our engineer to guide the installation for you. But the relevant cost should be paid by your company such hotel, food, round trip ticket.
