High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access
Specifications
Brand Name :
EliteLED
Model Number :
P4 P5 P8 P10
Certification :
CE, CCC
Place of Origin :
Guangdong, China
MOQ :
1sqm
Price :
Negotiable
Supply Ability :
3000sqm/month
Delivery Time :
18 days
Packaging Details :
Wooden cases or flight cases
Application :
Outdoor Advertising
Pixel Pitch :
5mm, 8mm
Brightness :
7600nits
Product name :
P5 Outdoor Led Panel
Cabinet size :
Customized
LED chip :
Nationstar, Kinglight
Control system :
Nova
Certificate :
CE ROHS
Warranty :
2 Years
Description

Front Access Advertising Outdoor Fixed LED Display Nova System

Specifictions:

1. Low power consumption, low heat, energy saving and environmental protection.

2. Uniform color, high contrast, the picture is beautiful and natural.

3. Short leading time for fast delivery.

4. Certification:EMC, FCC, IP65

5.. Patent mask design, dust-proof and waterproof, protection level up to IP65.

LED Screen Information View Distance In/meter 392/10
View Angle (H/V) Deg. 140/140
LED Type N/A SMD3535
Pixel Pitch Unit 10
Brightness Nits 6500
Module Dimension(WxH)
 In/mm 12.6x6.3/320x160
Module Pixel(WxH)
 Pixel 32x16
Cabinet Dimension(WxH)
 In/mm 37.8x37.8/960x960
Cabinet Pixel(WxH)
 Pixel 96x96
Cabinet Weight
 Kg 50
Cabinet Material
 N/A Steel
Maintenance Way
 N/A Rear
Power Operating AC Operation V AC100~240V 50-6-Hz switchable
Power Consumption(Max./Ave.) W/m2 730/220
Control System
Refresh Rate
 Hz 1920
Driving Type
 Scan 1/2
Digital Processing
 Bit 14
Gray Scale
 Level 16384
Support Input
 N/A Composite video,S-video,DVI,HDMI,SDI,HD-SDI
Control Distance
 Meter Ethernet cable within 100 meters, Optical fiber within 5KM
Raliability Ingress Protection N/A IP65 front/IP54 back
Operating Humidity RH 10~95%
Operating Tem. F/C -4F~140F/-30~60
Life Time(50% brightness) Hour 100,000

High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access

High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access

High Contrast AC100~240V Outdoor Advertising Billboard P5mm Front Access

Services:


1. Warranty


1) We provide warranty of all components for 2 full years. During this time, we will replace or repair our goods for free if there is something wrong with them.
2) We will provide maintenance for a lifetime and charge for the raw materials only.

2. Technology Training


1) We provide the technology training for free, which contains the installation of software and hardware, as well as the daily operation and troubleshooting of the LED display.
2) We also provide lifetime consultation by E-mail, Skype, WhatsApp or other ways for free.

3. Certification


We provide the operation manual and all kinds of certification such as CE, RoHS EMC UL and so on.

4. Package&Shipment


1) Usually, we will ship within 20-25 working days after the customer place an order, but the actual arrival time is affected by transportation environment and other aspects.
2) In general,our products are packed in wooden boxes and flight case

LED display, also called led screen, led video wall, or led sign, with its unique advantages,has gradually replaced the traditional billboards, light boxes,projectors etc. LED display has become a new force in the media industry.
