LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events
Specifications
Place of Origin :
Guangdong, China
Model Number :
Smart
Brand Name :
Excel LED
Supply Ability :
5000 Square Meter/Square Meters per Month
Packaging Details :
Flight Case
MOQ :
1 - 19 Square Meters
Price :
$1,100.00
Certification :
CCC,CE, FCC
Delivery Time :
15 working days
Application :
Event; Wedding; Concert
Color :
RGB, 3 in 1, full color
Panel Size :
500x500mm
Pixel Pitch :
2.6,2.84,2.97,3.91, 4.81mm
Pixel density :
65536dots/m2
Module size :
250*250mm
LED chip :
Kinglight, Nationstar,K-N light
Brightness :
800-1000cd/sqm
Refresh rate :
3840Hz
Voltage :
110-240V/50-60HZ
Cabinet material :
Aluminum Cabinet
Cabinet design :
front service & magnetic connection;
Certificate :
CE ROHS FCC
Screen Dimension :
80inch, 110inch, 140inch, 210inch
Port :
Shenzhen
Description

LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events

-- Design for Your High-end Events --
Indoor Display
Value
Smart 2.6
Smart 2.84
Smart 2.97
Smart 3.91
Pixel pitch
2.6mm
2.84
2.97
3.91
Pixel Configuration
SMD, 3 in 1
SMD, 3 in 1
SMD, 3 in 1
SMD, 3 in 1
Brightness
1000nits
1000nits
1000nits
1000nits
Brightness adjustable
Manually / automatically
Manually / automatically
Manually / automatically
Manually / automatically
Colors
281 trillion
281 trillion
281 trillion
281 trillion
Refresh Rate
3840Hz
3840Hz
3840Hz
3840Hz
Panel size
500 x 500 x 88mm
500 x 500 x 88 mm
500 x 500 x 88 mm
500 x 500 x 88 mm
Module size
250 x 250 mm
250 x 250 mm
250 x 250 mm
250 x 250 mm
Panel material
Aluminum
Aluminum
Aluminum
Aluminum
Pixel Matrix per panel
192 x 192 dots
176 x 176 dots
168 x 168 dots
128 x 128 dots
Pixel density per sqm
147456 dots
123904dots
112896 dots
65536 dots
Viewing angle (H/V)
140/140
140/140
140/140
140/140
Power Consumption(Max/Avg)
710 / 240 W.h/sqm
710 / 240 W.h/sqm
710 / 240 W.h/sqm
710 / 240 W.h/sqm
IP Rate (front/ rear)
IP40/IP20
IP40/IP20
IP40/IP20
IP40/IP20
Input Voltage (AC)
110 / 240V
110 / 240V
110 / 240V
110 / 240V
Panel weight (kg)
7.2 (Alu.)
7.2 (Alu.)
7.2 (Alu.)
7.2 (Alu.)
Ideal Lifetime (h)
100000
100000
100000
100000
Maintaining type
Front/Rear
Front/Rear
Front/Rear
Front/Rear
Outdoor Display
Value
Smart 3.47
Smart 3.91
Smart 4.81
Pixel pitch
3.47mm
3.91
4.81
Pixel Configuration
SMD, 3 in 1
SMD, 3 in 1
SMD, 3 in 1
Brightness
4500nits
4500nits
4500nits
Brightness adjustable
Manually / automatically
Manually / automatically
Manually / automatically
Colors
281 trillion
281 trillion
281 trillion
Refresh Rate
3840Hz
3840Hz
3840Hz
Panel size
500 x 500 x 88mm
500 x 500 x 88 mm
500 x 500 x 88 mm
Module size
250 x 250 mm
250 x 250 mm
250 x 250 mm
Panel material
Aluminum
Aluminum
Aluminum
Pixel Matrix per panel
144x 144 dots
128 x 128 dots
104 x 104 dots
Pixel density per sqm
82944 dots
65536 dots
43264 dots
Viewing angle (H/V)
140/140
140/140
140/140
Power Consumption(Max/Avg)
710 / 240 W.h/sqm
710 / 240 W.h/sqm
600 / 210 W.h/sqm
IP Rate
IP65
IP65
IP65
Input Voltage (AC)
110 / 240V
110 / 240V
110 / 240V
Panel weight (kg)
7.2 (Alu.)
7.2 (Alu.)
7.2 (Alu.)
Ideal Lifetime (h)
100000
100000
100000
Maintaining type
Front/Rear
Front/Rear
Front/Rear

LED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for EventsLED Wall Screen P2.84 P3 P4 500x500mm Aluminnum 3840HZ 4500CD for Events

Product Features
Front & Rear service Front and Rear serviceable cableless connection Module, suitable for multi applications . New cabinet design Die-casting aluminum cabinet frame applies latest molding workmanship, which ensures its accuracy and durability. Easy maintenance Integrated power and signal Individual box,easy and fast to be replaced during Events. Curve Installation Advanced Inner and outer curve lock systems Curve Installation is available for both 500*500mm and 500*1000 mm cabinets Fast-lock system 1,Fast-lock system with ergonomic design. 5 seconds’ instant installation 2,500*500 mm cabinets and 500*1000mm cabinets can match each other easily.
FAQ

Q:What is your MOQ?

A:Any quantity is acceptable for your order.

Q:When will you make the delivery?

A:We can make the delivery within 3-5 working days for the led modules and 10-12days for the led finished screen according to the size and quantities of your order.

Q:What technical supports can you offer?

A:We provide all kinds of technology training for free, including the operation and maintenance training of the LED screens in our factory. we can send an engineer team to the country of the customer to instruct the installation in necessary.


Q:Do you provide any free spare parts in each order?
A:Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.

Q: Can you offer a technical support? Since it's my first time....

A:We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems. Our engineer can directly teach you how to control, or help you to done if you are really don't know how to control(Our Engineer can text English, we can saving more time )

We're devoted to innovative high-end led display with over 10 years manufacturing experience, and we believe you could get a professional solution and best service. We're happy to serve you.

If you need led display screen,welcome to contact us,we can customize according to your needs.

For more questions about EXCEL LED full color smd outdoor/indoor led video display screen fixed with iron cabinet , please contact me right now!
