CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
Specifications
Place of Origin :
Guangdong, China
Model Number :
H3
Brand Name :
Excel LED
Supply Ability :
5000 Square Meter/Square Meters per Month
Packaging Details :
Plywood box + pallet
MOQ :
1 Square Meters
Certification :
CCC,CE, FCC
Payment Terms :
Western Union, L/C, T/T
Delivery Time :
15 working days
Application :
shopping mall; wedding; concert; party, church,
Color :
RGB, 3 in 1, full color
Panel Size :
500x500mm
Pixel Pitch :
3.91mm, 4.81
Pixel density :
65536dots
Module size :
250*250mm
LED chip :
Kinglight, Nationstar,K-N light
Brightness :
800-1000cd/sqm
Refresh rate :
3840Hz
Voltage :
110-240V/50-60HZ
Cabinet material :
Aluminum Cabinet
Cabinet design :
front service & magnetic connection;
Certificate :
CE ROHS FCC
Screen Dimension :
80inch, 110inch, 140inch, 210inch
Port :
Shenzhen
Description
Only 8 seconds Installation screen 500 x 500mm pitch P3.91mm LED Video Wall panel
-- Your right choice for indoor fixed application --
Value
H2
H3
H4
Pixel pitch
2.6mm
3.91
4.81
Pixel Configuration
SMD, 3 in 1
SMD, 3 in 1
SMD, 3 in 1
Brightness
1000nits
1000nits
1000nits
Brightness adjustable
Manually / automatically
Manually / automatically
Manually / automatically
Colors
281 trillion
281 trillion
281 trillion
Refresh Rate
1920Hz/3840Hz
1920Hz/3840Hz
1920Hz/3840Hz
Panel size
500 x 500 x 80 mm
500 x 500 x 80 mm
500 x 500 x 80 mm
Panel material
Aluminum
Aluminum
Aluminum
Pixel Matrix per panel
192 x 192 dots
128 x 128 dots
104 x 104 dots
Pixel density per sqm
147456 dots
65536 dots
43264 dots
Viewing angle (H/V)
140/140
140/140
140/140
Power Consumption(Max/Avg)
710 / 240 W.h/sqm
710 / 240 W.h/sqm
710 / 240 W.h/sqm
IP Rate (front/ rear)
IP40/IP20
IP40/IP20
IP40/IP20
Input Voltage (AC)
110 / 240V
110 / 240V
110 / 240V
Panel weight (kg)
4.2 (Alu.)
4.2 (Alu.)
4.2 (Alu.)
Ideal Lifetime (h)
100000
100000
100000
Maintaining type
Front
Front
Front

Product Features
Light Weight: only 4.2kgs per cabinet, saving shipping cost.
High Refresh Rate: ≥3840Hz
Easy Installation: fatest installation with 2 seconds per cabinet；zero screws installation.
Efficient Maintenance: Front / Rear service.

CCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum CabinetCCC IP40 P3.91 LED Video Wall Panel 500X500mm Aluminum Cabinet
About Us

Excel LED has over ten (10) years experiences in providing LED Screen solutions worldwide. Many companies now offer LED screens, but few can match Excel’s pedigree. In recent years, the LED screen market has expanded rapidly, with any number of opportunistic companies offering screens at sometimes unbelievable prices. Excel LED are not one of these. Our screens are not "off the shelf" products; they are carefully researched, designed and produced in-house to the highest industry standards with ISO specification, which gives us pride in ourselves and products.

At EXCEL LED, we ensure that the finest engineering is combined with the very latest and efficient manufacturing techniques, thereby maximizing value to our customers, This approach is borne out of Excel‘s long experience in the LED market; having installed our very first set of full color LED screens over nine (9) years ago, we have been ceaselessly researching and working with LED technology ever since, making us one of the most experienced name in the industry. This knowledge translates into our product design, with a host of features incorporated to optimize picture quality, durability and reliability.

FAQ

Q. Is it OK to print my logo on led screen cabinet?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q: Do you offer guarantee for the products?

A: Yes, usually we offer 2 years warranty for the screen body and 1 year for other spare parts, if want longer warranty years, we can discuss.

Q:Are you a manufacturer or trading company?

A:We are a Professional OEM/ODM manufacturer which has specialized in led display industry for more than 10 years.

Q:How does your factory do regarding quality control?

A:Quality is priority.Our company have a strict rule in quality control. We focus on every detail,Our factory has gained ISO9001, ISO14001, CE, RoHS ,FCC authentication.

Q:What is your MOQ?

A:Any quantity is acceptable for your order.

Q:When will you make the delivery?

A:We can make the delivery within 3-5 working days for the led modules and 10-12days for the led finished screen according to the size and quantities of your order.

Q:What technical supports can you offer?

A:We provide all kinds of technology training for free, including the operation and maintenance training of the LED screens in our factory. we can send an engineer team to the country of the customer to instruct the installation in necessary.


Q:Do you provide any free spare parts in each order?
A:Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
