MPPT Lead Acid Battery 10A 20A 30A 40A Solar Panel Battery Charge Controller 12V 24V 48V
MPPT Lead Acid Battery 10A 20A 30A 40A Solar Panel Battery Charge Controller 12V 24V 48V
MPPT Lead Acid Battery 10A 20A 30A 40A Solar Panel Battery Charge Controller 12V 24V 48V
MPPT Lead Acid Battery 10A 20A 30A 40A Solar Panel Battery Charge Controller 12V 24V 48V
Specifications
Brand Name :
JNGE POWER
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Place of Origin :
Guang dong
Certification :
CE ROHS
Place Of Origin :
China
Model Number :
JN-MPPT-B
Rated Voltage :
12v 24v 48v Auto
Color :
Blue
Description

JN-MPPT-A 10A 20A 30A 40A MPPT Solar Panel Battery Charge Controller 12V 24V 48V JN-MPPT-A 10A 20A 30A 40A MPPT Sola

JN-MPPT-B Solar controller series ranked the first place among MPPT solar charge controllers, the advantage includes high conversion efficiency, wide range of PV input, professional PC monitoring software etc.. This is the most advanced version of MPPT solar charge controller.

Features:

1.12V 24V 48V system voltage auto identify.

2. MPPT charging efficiency more than 99.5%.

3. Support RS485 communication interface,more intelligent.(optional)

4. Strong data storage, storage time can be up to 10 years.

5. Synchronous rectification technology, ensure higher conversion efficiency under small power

charging condition.

6. Dual peaks and multi-peak tracking technology.

7. Japan imported power kits with better performance and more durable.

8. Common cathode circuit design makes the system more stable and reliable.

9. Support for parallel conenction, 99 sets max.

10.Super heat sink and fanless design with no nosie and free maintenance-free.

Parameters:

Parameters Name The parameter values (and adjustable range) Default values
Current 30A 40A 50A 60A
System Voltage 12V,24V,48V
Photovoltaic max input voltage

100V (12V system Voltage)

150V(suggest lower than 145V)(24Vsystem Voltage)

150V(suggest lower than 145V)(48Vsystem Voltage)
Rated working current 30A 40A 50A 60A
Photovoltaic max input power

400W/12V

800W/24V

1600W/48V

500W/12V

100W/24V

1500W/48V

600W/12V

1200W/24V

2400W/48V

800W/12V

1600W/24V

3200W/48V
MPPT efficiency ﹥99.5%

Conversion

efficiency

 ﹥96%
Over voltage (over charge) 16～17V,×nV 16V,×nV
Over voltage recovery 15～15.5V, ×nV 15V,×nV
Charging limit voltage 15.5～16V, ×nV 15.5V,×nV
Equalizing charge voltage 15～15.5V, ×nV 15.2V,×nV
Boost charge voltage 14～15V, ×nV 14.4V,×nV
Boost charge recovery 12.3～13.5V,×nV 13.2V,×nV
Floating charge voltage 13.2～14.0,×nV 13.8V,×nV
Over discharge voltage 9.8～11.8V,×nV 10.8V,×nV
Over discharge recovery 12.0～13.0V,×nV 12.6V,×nV
Equalizing charge time 1/2/3 hour 1H
Boost charge time 1/2/3 hour 1H
Device address 1～99 6
Light control OPEN voltage 1～5V 5
Light control CLOSE voltage 5～11V 6

Light control

time delay

 10 min
Temperature compensation 0～4 4
Over temperature protection When the temperature reaches 75 ℃ charging current is limited to half of the rated current, When the temperature reaches 90 ℃ charging and load are shut off
Working temperature -20℃～50℃
Storage temperature -40℃～80℃
Humidity 10% ～ 90% Non-condensate
Weight 6.55kg
Size 280*225*114mm

Product Advantages:

1. 12V 24V 48V system voltage auto identify.

2. MPPT charging efficiency more than 99.5%.

3. Fanless design with no nosie and free maintainless

4. With RS485 communication interface,more intelligent.

5. Support data storage, storage time can be up to 10 years.

6. Synchronous rectification technology.

7. Dual peaks and multi-peak tracking technology.

8.Japan imported power kits with better performance and more durable.

9. Common cathode circuit design makes the system more stable and reliable.

10. Support for parallel conenction, 99 sets max.

11.Super heat sink and fanless design with no nosie and free maintenance-free.

Product Parameters:

Parameters Name The parameter values (and adjustable range) Default values
Current 10A 20A 30A 40A
System Voltage 12V,24V,48V
Photovoltaic max input voltage

20V～100V(12V system Voltage)

40V～150V(suggest lower than 145V)(24Vsystem Voltage)

80V～150V(suggest lower than 145V)(48Vsystem Voltage)
Rated working current 10A 20A 30A 40A
Photovoltaic max input power

120W/12V

240W/24V

480W/48V

240W/12V

480W/24V

960W/48V

360W/12V

720W/24V

1440W/48V

480W/12V

960W/24V

1920W/48V
Output Rated Current 10A 15A 20A 20A
MPPT efficiency ﹥99.5%

Conversion

efficiency

 ﹥96%
Over voltage (over charge) 16～17V,×nV 16V,×nV
Over voltage recovery 15～15.5V, ×nV 15V,×nV
Charging limit voltage 15.5～16V, ×nV 15.5V,×nV
Equalizing charge voltage 15～15.5V, ×nV 15.2V,×nV
Boost charge voltage 14～15V, ×nV 14.4V,×nV
Boost charge recovery 12.3～13.5V,×nV 13.2V,×nV
voltage 13.2～14.0,×nV 13.8V,×nV
Over discharge voltage 9.8～11.8V,×nV 10.8V,×nV
Over discharge recovery 12.0～13.0V,×nV 12.6V,×nV
Equalizing charge time 1/2/3 hour 1H
Boost charge time 1/2/3 hour 1H
Device address 1～99 6
Light control OPEN voltage 5～11V 5
Light control CLOSE voltage 5～11V 6

Light control

time delay

 10min
Temperature compensation 0～4 4
Over temperature protection When the temperature reaches 75 ℃ charging current is limited to half of the rated current, When the temperature reaches 90 ℃ charging and load are shut off
Working temperature -20℃～50℃
Storage temperature -40℃～80℃
Humidity 10% ～ 90% Non-condensate
Weight 2.15kg
Size 185*193*80mm(20～30A)
