Specifications
Brand Name :
MPLED
Model Number :
P2
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000sqm
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case/ wooden case/ carton/ it is up to you
Product name :
Curved LED Screen
Module size :
320x160mm
Cabinet size :
Customized
Driving mode :
1/40 scan
Signal input format :
HDMI,DVI,SDI,VGA etc.
Gray scale :
16 bit
Description

MPLED Curved Indoor Flexible LED Displays Full Color FCC Approved

Curved LED Screen P2 Indoor Flexible Custom Soft Interactive Module

Product description

1. Led special-shaped screen led full-color screen led flexible screen bendable led screen S-shaped led display wave-shaped led twisted electronic screen night field, bar, PUB bar, club application

2. The product supports a variety of signal inputs, such as AV, DP, VGA, DVI, YPbPr, HDMI, SDI, H-SDI, etc.

3. Most of the installation methods are magnetic column suction, and the installation method of "one installation is ready" is adopted, that is, the customization of the shape is completed according to the customer's needs, and then it can be directly adsorbed to achieve one-step installation.

4. The magnetic installation method is as simple as the conventional indoor screen installation method, and the box body connection lines are all connected by quick butt joints, which are firm and reliable.

5. It can be arbitrarily shaped, among which the cylindrical screen has high brushing performance and can be hoisted, seated, hung, etc., to meet the requirements of the site to the greatest extent.

Pixel Pitch 2mm
LED Lamp SMD2121
LED configuration SMD 3 in 1
Module Size 320mm x 160mm
Module pixels 160x80dots
Average Power/sqm (watts) 159
Max Power/sqm(watts) 530
Brightness 800cd/㎡
Viewing Angle H:160°, V:120°
Best Viewing Distance 2-200 meters
Brightness Control 256 level
Gray scale 14 bit
Refresh frequency 3840 hertz
Driving mode 1/40 scan
Input power frequency 50 or 60 Hertz
Input Voltage 110 ~ 240 Volt,60Hz
Blind spot rate <1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP31
Operating temperature ﹣20 ~﹢60 ℃
Operating humidity 10% ~ 90%
Control distance CAT5 cable:<100 m; Single mode fiber:<10 km
Signal input format HDMI,DVI,SDI,VGA etc.
Operating system Windows (2000/XP/Vista/7/8/10)

MPLED Curved Indoor Flexible LED Displays Full Color FCC ApprovedMPLED Curved Indoor Flexible LED Displays Full Color FCC Approved

Projects

2017, MPLED P6 outdoor led display assist for Senator Election of South Korea

2018, MPLED P10 outdoor led display light up in The World Cup in Russia

2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia

2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino

2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL

2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark

FAQ

Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.

Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity.For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
