1.5mm Front Access Led Display Board 3840Hz Refresh Rate 3D Immersive
1.5 Mm Led 3D Immersive Led Display Modular Panel Shooting Studio Screen
Product description
1. Widely used in commercial display, indoor fixed advertising, auditorium, conference room, banquet, vestibule, exhibition demonstration, transportation, studio, command control.
2. 160° horizontal and vertical viewing angle and increased grayscale capabilities.
3. According to video size 16:9 and 4:3, the product fit the signal of security monitoring, scheduling command cabinets form a 16:9 size LED display, also compatible with 4:3 video source to satisfy clients requirement.
4. Magnetically modules and fully front serviceable design, easy installation and maintenance.
5. 3840Hz refresh rate which eliminates scan lines and flicker in your display on camera.
Pixel Pitch | 1.5mm | |||
LED Lamp | SMD1212 | |||
IC | ICN2153 | |||
Module Size | 320x160mm | |||
Module pixels | 208x104dots | |||
Cabinet Size(WxH)(mm) | 680x480mm | |||
Module Quantity(pcs) | 6 | |||
Cabinet resolution WxH | 516x312dots | |||
Cabinet Material | Aluminum die casting | |||
Cabinet Weight (kg) | 7 | |||
Average Power/sqm (watts) | 200 | |||
Max Power/sqm(watts) | 600 | |||
Brightness | 800cd/㎡ | |||
Viewing Angle | H:160°, V:120° | |||
Best Viewing Distance | 1.8-200 meters | |||
Brightness Control | 256 level | |||
Gray scale | 16 bit | |||
Refresh frequency | 3840hertz | |||
Driving mode | 1/26 scan | |||
Input power frequency | 50 or 60 Hertz | |||
Input Voltage | 110 ~ 240 Volt,60Hz | |||
Blind spot rate | <1/10000 | |||
Lifetime at 50% brightness | 100000 hours | |||
Ingress Protection | IP30 | |||
Operating temperature | ﹣20 ~﹢60 ℃ | |||
Operating humidity | 10% ~ 90% | |||
Control distance | CAT5 cable:<100 m; Single mode fiber:<10 km | |||
Signal input format | HDMI,DVI,SDI,VGA etc. | |||
Operating system | Windows (2000/XP/Vista/7/8/10) |
One- Stop Solution Service
1.3D/CAD engineering drawing to confirm project execution/implementation as presale service within 72 hours.
2.Free CAD drawings for steel structure, signal/power connections of led display which guide for site cable arrangement and structure preparation in advance.
3.7/24 online remote control service , and local engineer service within 8 hours contact.
4.Free technical training in factory.
5.MPLED engineers will fly to the site if you need local service.
6.Expanding market plan with professional MPLED team over 8 years experience.
7.Multiple options for global transportation, like FOB, CIF, DDP, DDU to most countries.
FAQ
1. Payment Terms?
We accept payment by bank transfer (T/T) , Credit Card on Alibaba, or other payment terms you want that can contact us, payment should be paid before delivery .
2. Shipment Way?
You can choose to use sea shipment or air freight or express by DHL or such as this(UPS,FEDEX,TNT,EMS, ARAMEX).We can help you to book ship or arrange the shipment, or you can use your own shipping agent.
3.Warranty?
We offer a 3 year warranty service according different order, and to provide technical guidance.We have a professional service team; They are always online waiting to serve you.
During the warranty period, most of damaged parts could be replaced free of charge.
4.Packaging ways for our led screen?
We provide Flight case or wooden case for led display board. Customers can freely choose from them. But in any case, we will both ensure the use of appropriate packaging to protect led display board safety.
5. Delivery time?
It will depond on your project size
